800*600mm Automatic Rigid Box Forming Machine 45PCS/Min

1 SET
MOQ
Negotiable
Price
800*600mm Automatic Rigid Box Forming Machine 45PCS/Min
Features Gallery Product Description Request A Quote
Features
Specifications
Classification: Paper Box Making Machine
Paper Thickness: 80-350 G/Sqm
Working Speed: 15-45 PCS/Min
Max. Paper Size: L800 * W600mm
Min. Paper Size: L135 * W100mm
Cardboard Thickness: 0.8-3mm
Edge Folding Size: 10-90mm
Max. Cardboard Size: L760 * W560mm
Tuin In Depth: 15-80mm
High Light:

Automatic Rigid Box Forming Machine

,

800*600mm Rigid Box Forming Machine

,

Rigid Box Forming Machine 45PCS/Min

Basic Infomation
Place of Origin: China
Brand Name: EcooGraphix
Certification: ISO9000, CE
Model Number: ECOO-LS1246D
Payment & Shipping Terms
Packaging Details: Standard Export Packing
Delivery Time: 45 Days
Payment Terms: L/C, T/T
Supply Ability: 500 Sets/Year
Product Description



 800*600mm Max. Paper Size Automatic Rigid Box Former











--------------------------------------------------------------------------------------------------------------------------------



██  Paper Box Making Machine Application  ██



Quick job setting

No need to change air pressing plate;​

No need to change truck in blade;

No need to move camera for size changing, quick job changing.


Make High-end boxes

Special pick up and wrapping system

Can use carton paper to wrap the inner box

Can make big size box, such as 600*400mm and the height can reach 120mm

Storage(memory) function for size setting



Suitable for changeable orders, such as 10000 pieces for one order.








--------------------------------------------------------------------------------------------------------------------------------



██  Specification  ██



Heaven and earth box forming machine

Model
ECOO-LS1246D

Paper size (max)
L800 * W600mm

Paper size (min)
L135 * W100mm

Max. cardboard size
L760 * W560mm

Min. cardboard size
L120 * W100mm

Max. box size
L600 * W400 * H120mm

Min. box size
L80 * W65 * H15mm

Paper thickness
80-350g/sqm

Cardboard thickness
0.8-3mm

Edge folding size
10-90mm

Turn in depth
15-80mm

Air pressure
40L/min 0.8MPa

Working speed
15-45 pcs/min

Motor power
14kw/380v 3 phase

Heating power
8kw/380v 3 phase

Machine weight
4300kg

Machine dimension
L6600 * W4200 * H3000mm
Heaven And Earth Box Forming Machine
Model ECOO-LS1246D
Paper size (max) L800 * W600mm
Paper size (min) L135 * W100mm
Max. cardboard size L760 * W560mm
Min. cardboard size L120 * W100mm
Max. box size L600 * W400 * H120mm
Min. box size L80 * W65 * H15mm
Paper thickness 80-350 g/sqm
Cardboard thickness 0.8-3mm
Edge folding size 10-90mm
Turn in depth 15-80mm
Air pressure 40L/min, 0.8MPa
Working speed 15-45 pcs/min
Motor power 14kw/380v 3 phase
Heating power 8kw/380v 3 phase
Machine weight 4300kg
Machine dimension L6600 * W4200 * H3000mm





--------------------------------------------------------------------------------------------------------------------------------



██  Features  ██



1. Fast-size changing controlled by servo motor


2. Servo motor driving paper feeding which avoid double paper feeding


3. Box picking up system,avoid paper scratching


4. Integration glue collection tube,easy to wash


5. Integration tape feeding device,avoid tape blocking


6. Double 10 Mega Pixel Cameras from Germany


7. Robotic arm from Yamaha's working accuracy is 0.1mm


8. No need to move camera


9. High speed, could reach 45 piece/min









--------------------------------------------------------------------------------------------------------------------------------



██  Producing And Packaging  ██



From producing to delivery, we make every details very carefully to guarantee the good product quality and service to customers.



800*600mm Automatic Rigid Box Forming Machine 45PCS/Min 0



800*600mm Automatic Rigid Box Forming Machine 45PCS/Min 1

800*600mm Automatic Rigid Box Forming Machine 45PCS/Min 2



800*600mm Automatic Rigid Box Forming Machine 45PCS/Min 3



800*600mm Automatic Rigid Box Forming Machine 45PCS/Min 4



800*600mm Automatic Rigid Box Forming Machine 45PCS/Min 5



800*600mm Automatic Rigid Box Forming Machine 45PCS/Min 6



800*600mm Automatic Rigid Box Forming Machine 45PCS/Min 7









--------------------------------------------------------------------------------------------------------------------------------



██  Certifications  ██



800*600mm Automatic Rigid Box Forming Machine 45PCS/Min 8



800*600mm Automatic Rigid Box Forming Machine 45PCS/Min 9









--------------------------------------------------------------------------------------------------------------------------------



██  FAQ  ██


Q1: What are your main products ?

A: Our main products are the Prepress 4up and 8up Online/Offline Thermal CTP, CTCP, VLF CTP, Flexo CTP, Processor, Offset Plates, Offset Inks, Offset Printing Blankets, Postpress Packing Equipment and so on.

You can get the equipment and consumables all in one and no worry about the after-sales service from our company.






Q2: Where is your factory ?

A: Our CTP Processor machine factory is in Shanghai, you are warmly welcome to visit our factory!






Q3: What is your warranty for the CTPs ?

A: Three years' Laser Head and main spare parts for the CTPs, one year for the Processor.



If the customer uses EcooGraphix CTP plate with the CTP machine, we will provide the Lifetime Warranty.






Q4: Can you also supply the Workflow and RIP ?

A: Yes, we can provide the Workflow Brainnew and RIP Compose V12.






Q5: What about the installation and after-sales technician support ?

A: Our engineer can go to help the installation and provide the necessary training. The buyer should take the round air plane tickets, service charge and the local accommodation cost. Any problems or questions, we will be at your disposal 7x24 hours. Among our large amount of CTP installations worldwide, there are also many end users(printers) who have purchased the CTP products from EcooGraphix China directly and EcooGraphix technical service team support these installations remotely with regular onsite visits.



These end users printers all run the CTP systems with full satisfaction due to our robust quality, seamless remote service, thorough training and maintanence. If you are a printer who is considering purchasing directly from EcooGraphix China, there is no hassle on installations, training and after sales service. We guarantee your satisfaction.
