Name: Double Layered Thermal CTP Plate ECOO-TSR For Offset Printing
Brand: Hangzhou Ecoographix Digital Technology Co., Ltd.
SKU: ECOO-TSR
Price: 34.35 USD
Availability: InStock

Features Gallery Product Description Request A Quote

Features

Specifications

Product Name: Double Coating Long Run-Length Thermal CTP Plate For UV Ink Offset Printing

Plate Type: Positive Working Thermal CTP Plate(Double Layer)

Application: High Grade Offset Commercial, Packaging Or Newspaper

Plate Thickness: 0.15, 0.20, 0.25,0.30, 0.40 Mm

Maximum Short Grain Width: Maximum Width 1325 Mm

Length Of Run: Ordinary Ink: 200,000 To 400,000 Impressions Unbaked

Spectral Sensitivity: 800-850 Nm – Peaks 830nm

Resolution: 1-99% At 400 LPI Or FM 10 Micron Stochastic

Safelight: Daylight Handling

Shelf Life: 12 Months Under Recommended Storage Conditions

Storage And Handling: Stored In A Cool And Dry Environment, Away From Excessive Cold, Heat And Humidity.

Highlight:

Double Layered Thermal CTP Plate

Offset Printing Thermal CTP Plate

ECOO-TSR Thermal CTP Plate

Basic Infomation

Place of Origin: CHINA

Brand Name: EcooGraphix

Certification: CE, ISO900

Model Number: ECOO-TSR

Payment & Shipping Terms

Packaging Details: Standard Exporting Wooden Pallet

Delivery Time: 30 DAYS

Payment Terms: L/C, T/T

Supply Ability: 5000, 000sqm

Gallery

Double Layered Thermal CTP Plate ECOO-TSR For Offset Printing

Product Description

Double Coating Thermal CTP Plate for UV Ink Offset Printing

The Double Layer Coating Thermal CTP Plate ECOO-TSR is a positive-working plate designed for commercial printing. It is bakeable and compatible with both ordinary and UV inks, making it versatile for various printing applications.

Features

1. Super long running length

- Ensures extended use without compromising quality.

2. workable with UV ink

- Suitable for printing with UV inks, providing flexibility in ink choice.

3. solvent resistant

- Offers high resistance to solvents, enhancing durability and performance.

Application

The ECOO-TSR plate is ideal for commercial printing, newspaper printing, and package printing. Its robust design and compatibility with various inks make it an excellent choice for customers seeking a reliable and high-performing thermal CTP plate.

Specification

Model	ECOO-TSR
Plate Type	Positive Thermal Digital Plate
Application	Commercial, newspaper, and packaging print
Substrate	Electro chemically Grained and Anodized lithographic Aluminum
Gauge	0.15, 0.30mm
Maximum short grain width	Maximum width 1280 mm
Coating	Blue
Length of Run	Unbaked: 400,000 impressions UV Ink:100,000 impressions
Plate setters	All thermal CTP machine
Aluminum	Standard 1050 Alloy
Exposure energy	120 - 150 mj/ m²
Developing time	25-30 sec
Spectral Sensitivity	780 - 850 nm
Resolution	1-99% @ 400LPI
Developer	Ecoo DV-T Series Developer
Processing temperature	23ºC+/-2ºC
Processing Speed	0.80 - 1.20 m/min
safelight	Daylight handling
Shelf life	12-18 months under recommended storage conditions
Packaging	Available in all standard formats, including bulk packaging options such as APL packaging
Storage and handling	Stored in a cool and dry environment, away from excessive cold, heat and humidity
