50-70 Mj/Sqm CTCP Offset Aluminum CTP Printing Plates High Sensitivity UV CTP Plate

Offset Printing Aluminum Plate High Sensitivity UV CTP Plate

 1. Application

EcooGraphix CTCP Plate can be used for long runs high-grade commercial and newspaper printing.
Unique production technology and high-quality raw materials make the plate

gain high photosensitive speed, good half-tone dot reproduction, and stable performance.

 2. Specification

General Information

Plate Model
ECOO-CTCP-ES

Plate Type
Positive CTCP Plate(Single Layer)

Application
High-quality commercial and newspaper printing

Substrate
Electrochemically grained and Anodized lithographic aluminum

Aluminum alloy
Standard 1050 Alloy

Gauge
0.15, 0.20, 0.25, 0.30, 0.40 (mm)

Maximum short grain width
Maximum width 1280 mm

Length of Run
Unbaked: 80,000 to 100,000 impressions; Baked: Over 100,000 impressions


Exposing

Plate setters
Luscher, Basysprint, Cron, EcooGraphix UV series CTCP machine

Exposure energy
50 - 70 mj/cm²

Spectral Sensitivity
400 - 430 nm - UV Laser

Resolution
2 - 99% @ LPI 200

Photosensitive Wave Length
405nm

Coating
Light Blue


Developing

Processor
All kinds of brands.

Developer
Any CTCP plate developer or our own developer

Processing temperature
23°C +/- 2°C

Developing time
25 - 30 sec

Processing Speed
0.80 - 1.20 m/min


Storage And Handling

Safelight
Handle under yellow safelight (UV free)

Shelf Life
12 months under recommended storage conditions

Packaging
Available in all standard formats, including bulk packaging options such as APL packaging

Storage and handling
Stored in a cool and dry environment, away from excessive cold, heat and humidity.

 3. Characteristics

High-quality Aluminum and photosensitive coating.

Multi-layer composite grain structure.

Precise half-tone dot reproduction.

High development tolerance level and convenient operation.

​

​

​​

​​

​​
