Automatic Food Paper Box Carton Erecting Machine Three Lanes
Model: L1350/3-A
Product Description:
Carton Erecting Machine is an automatic machine, specialize in making food carton, box, container which are made from cardboard, paper, paperboard, corrugated paper etc.
The food box (carton, container, dish, tray) is widely used as burger box, hot-dog box (tray), one block box, food pail box (Chinese food box, take-away box), fries box (chips box, chips tray), lunch box, meal box, etc.
It is highly efficient. The working speed of double station model is Max 200 pieces per minute(per lane) and finished produces are automatically counted. It can be customized to do different size and shaped boxes through changing mold.
Features:
The carton box erecting machine is designed in compact structure for convenient installation.
It comes with automatic counting function.
The small load power and the frequency control on motor speed enable stable operation and high working accuracy.
Apart from simple operation and convenient adjustment, the carton box forming machine offers low failure rate.
The servo control system is optional for the carton box making equipment to achieve high stability, small vibration, and high accuracy.
Specification:
| Model | L1350/3-A |
| Voltage | 380V/50HZ |
| Covering Area | 4.0M*1.8M |
| The total Power | 9KW |
| Maximum Production Speed | 600 pieces/min |
| Air Pressure | 0.6Mpa(Dry and clean compressed air) |
| Packing | 2960mm* 2000mm* 1500mm, N.W.: 2300KG, G.W.: 2550KG 1700mm* 1350mm* 900mm, N.W.: 250KG, G.W.: 350KG |
| Materials |
Paper Board 200-600gsm; corrugated board paper with thickness not exceed 1.5MM |
Application:
hamburger box, fried chips box, paper tray, noodle box, lunch box and other food container.
FAQ:
1. Guarantee:
There is 12 month guarantee of each machines since customer got the machine.
2. Delivery Time:
Around 30 days after get the deposit. Depends on different machines.
3. What is your package?
What the package we use is strong seaworthy wooden cases. Each machine will be protected by anti-rusted oil before put into the case and there are desiccants will be packed into the machine together.
4. Do you have Installation and Training service if we bought the machines from your company?
If customers request us to dispatch our engineer to their country for installation and training, customers should take all necessary cost, like return flight tickets, hotel, food.
