Heat Sealing Paper Box Making Machine Fast Food Carton Forming Machine

1 SET
MOQ
Negotiable
Price
Heat Sealing Paper Box Making Machine Fast Food Carton Forming Machine
Features Gallery Product Description Request A Quote
Features
Specifications
Classification: Paper Box Making Machine
Printing Material: 200-600gsm One Side Or Double Side PE Coating Paperboard
Max. Speed: ≤ 60pcs/min
Total Power: 5.5 Kw
Air Supply: 0.6MPa
Weight About: 1 Ton
Area: 4x3(m)
High Light:

60pcs/Min Paper Box Making Machine

,

5.5Kw Paper Box Making Machine

,

4x3m Paper Box Making Machine

Basic Infomation
Place of Origin: China
Brand Name: EcooGraphix
Certification: ISO9000, CE
Model Number: ECOO LH450A
Payment & Shipping Terms
Packaging Details: Standard Export Packing
Delivery Time: 45 Days
Payment Terms: L/C, T/T
Supply Ability: 500 Sets/Year
Product Description



 Heat Sealing Fast Food Carton Forming Machine







△ ▽▽ △△ ▽▽ △△ ▽  Introduction  △ ▽▽ △△ ▽▽ △△ ▽

Ecoo lunch box forming machine is designed according to European industrial standard. Initially developed in China, the products developed in China, the products have achieved the CE certification and have been sold to many countries in the world. With high quality and efficiency, it is an ideal choice for you to produce single PE coated or double PE coated paper lunch box. We adopt ceramic hot air to sealing the box corner on this kind of machine.






△ ▽▽ △△ ▽▽ △△ ▽  Specification  △ ▽▽ △△ ▽▽ △△ ▽

Lunch Box Forming Machine

Model
ECOO-LH450A

Machine size
2.3x1.5x1.7(m)

Power supply
380V/50HZ

Material
200-600gsm one side or double side PE coating paperboard

Air supply
0.6MPa

Total power
5.5kw

Max speed
≤ 60pcs/min

Weight
About 1Ton

Area
4x3(m)

Blank length(L)
≥200mm ≤520mm

Blank width(B)
≥200mm ≤500mm

Height of side flaps lid(H)
≥45mm ≤250mm

Blank bottom width(C)
≥60mm ≤170mm

Blank bottom length(D)
≥60mm ≤220mm

Blank cover length(H1)
≥50mm ≤270mm

Heat Sealing Paper Box Making Machine Fast Food Carton Forming Machine 0 Heat Sealing Paper Box Making Machine Fast Food Carton Forming Machine 1

Lunch Box Forming MACHINE
Model ECOO-LH450A
Machine size 2.3x1.5x1.7(m)
Power supply 380V/50HZ
Material 200-600gsm one side or double side PE coating paperboard
Air supply 0.6MPa
Total power 5.5kw
Max. speed ≤ 60pcs/min
Weight About 1Ton
Area 4x3(m)
Blank length(L) ≥200mm ≤520mm
Blank width(B) ≥200mm ≤500mm
Height of side flaps lid(H) ≥45mm ≤250mm
Blank bottom width(C) ≥60mm ≤170mm
Blank bottom length(D) ≥60mm ≤220mm
Blank cover length(H1) ≥50mm ≤270mm






△ ▽▽ △△ ▽▽ △△ ▽  Producing And Packaging  △ ▽▽ △△ ▽▽ △△ ▽

From producing to delivery, we make every details very carefully to guarantee the good product quality and service to customers.

Heat Sealing Paper Box Making Machine Fast Food Carton Forming Machine 2

Heat Sealing Paper Box Making Machine Fast Food Carton Forming Machine 3

Heat Sealing Paper Box Making Machine Fast Food Carton Forming Machine 4

Heat Sealing Paper Box Making Machine Fast Food Carton Forming Machine 5

Heat Sealing Paper Box Making Machine Fast Food Carton Forming Machine 6






△ ▽▽ △△ ▽▽ △△ ▽  Certifications  △ ▽▽ △△ ▽▽ △△ ▽

Heat Sealing Paper Box Making Machine Fast Food Carton Forming Machine 7

Heat Sealing Paper Box Making Machine Fast Food Carton Forming Machine 8






△ ▽▽ △△ ▽▽ △△ ▽  FAQ  △ ▽▽ △△ ▽▽ △△ ▽



 Q1: What are your main products ?

A: Our main products are the Prepress 4up and 8up Online/Offline Thermal CTP, CTCP, VLF CTP, Flexo CTP, Processor, Offset Plates, Offset Inks, Offset Printing Blankets, Postpress Packing Equipment and so on.

You can get the equipment and consumables all in one and no worry about the after-sales service from our company.



 Q2: Where is your factory ?

A: Our CTP Processor machine factory is in Shanghai, you are warmly welcome to visit our factory!



 Q3: What is your warranty for the CTPs

A: Three years' Laser Head and main spare parts for the CTPs, one year for the Processor.

If the customer uses EcooGraphix CTP plate with the CTP machine, we will provide the Lifetime Warranty.



 Q4: Can you also supply the Workflow and RIP ?

A: Yes, we can provide the Workflow Brainnew and RIP Compose V12.



 Q5: What about the installation and after-sales technician support ?

A: Our engineer can go to help the installation and provide the necessary training. The buyer should take the round air plane tickets, service charge and the local accommodation cost. Any problems or questions, we will be at your disposal 7x24 hours. Among our large amount of CTP installations worldwide, there are also many end users(printers) who have purchased the CTP products from EcooGraphix China directly and EcooGraphix technical service team support these installations remotely with regular onsite visits.

These end users printers all run the CTP systems with full satisfaction due to our robust quality, seamless remote service, thorough training and maintanence. If you are a printer who is considering purchasing directly from EcooGraphix China, there is no hassle on installations, training and after sales service. We guarantee your satisfaction.
