Conventional Offset Printing Plate Double Layer CTCP Plate UV-Ink Resistant
Model: CTCP-D
Product Description:
Specification:
| Model | ECOO-CTCP-D |
| Plate Type | No preheat, positive working, UV sensitive plate, double coated, no need baking for UV ink printing |
| Application | Newspaper Printing, commercial printing, and package printing |
| Substrate | Electrochemically Grained and Anodized Aluminum |
| Gauge | 0.15, 0.20, 0.25, 0.30, 0.40(mm) |
| Maximum short grain width | Maximum width 1350 mm |
| Developer | Any positive plate developer or our own developer |
| Length of Run |
200,000 impressions unbaked; 70,000 impressions with UV ink unbaked; |
| Plate setters Capability | All the main brands violet CTP in market, laser power no less than 30 mw |
| Aluminum | Standard 1050 Alloy |
| Exposure energy | 50-65uj/ cm²(based on plate setter and developing condition) |
| Developing time | 20±3 sec |
| Developing Temperature | 28±2ºC |
| Spectral Sensitivity | 405 nm |
| Resolution | 1-99% @ 200 LPI & 20 uFM |
| Shelf life | 12 months under recommended storage conditions |
| Storage and handing | Stored in a cool and dry environment, away from excessive cold, heat. |
| Product highlight |
High sensitivity; Extend laser life for image setter; Grain efficiency; Positive CTCP plate |
From producing to delivery, we make every details very carefully to guarantee the good product quality and service to customers.
Q2: How many Square Meters CTP plates can feed one 20' container?
A: About 20000-25000SQM
Q3: Can I take my own brand and label on the packing?
A: Yes, we can provide the OEM with the customer's brand and label.
