High Resolution Scanning Press Digital Inkjet Printer For Corrugated Box

1 SET
MOQ
Negotiable
Price
High Resolution Scanning Press Digital Inkjet Printer For Corrugated Box
Features Gallery Product Description Request A Quote
Features
Specifications
Classification: Digital Inkjet Printer
Application: Kraft, Coated, Personalization Such As Display Shelf, UV Solutions (PVC Expansion Sheet/Acrylic) Etc.
Max. Width: 2500mm
Ink Type: Water-based Ink
Printing Head: Industrial Inkjet Kyocera Print Heads With Piezo Technology
Printing Head Configuration: Standard: 8 Printheads, Double-row 4 Colors (CMYK), Maximum 8 Printheads
Printing Method: 1 Pass Or 2 Pass
Input Format: PDF, JPEG, TIFF, AI, CDR Etc.
Software: 3rd Party Rip
High Light:

Corrugated Box Digital Inkjet Printer

,

Digital Inkjet Printer 2500mm

,

PVC Expansion Digital Inkjet Printer

Basic Infomation
Place of Origin: China
Brand Name: EcooGraphix
Certification: ISO9000, CE
Model Number: ECOO 2500B
Payment & Shipping Terms
Packaging Details: Standard Export Packing
Delivery Time: 45 Days
Payment Terms: L/C, T/T
Supply Ability: 500 Sets/Year
Product Description



 Automatic Digital Scanning Inkjet Corrugated Carton Press









 ↘↘↘  Digital Inkjet Printer Specification



Model
HighJet 2500B

Applications
Kraft, Coated, Personalized Applications such as Display Shelf, UV Solutions (PVC Expansion Sheet/Acrylic) etc.

Ink Type
Han FullColor Water-Based Ink

Print head
Industrial inkjet Kyocera print heads with piezo technology

Dryer
IR & Hot air

Ink Supply
Automatic

Print head
Configuration Standard: 8 printheads, double-row 4 colors (CMYK), maximum 8 printheads

Capacity
1pass: 600sqm/hr;

2pass: 300sqm/hr

Media
Max. Width: 2500mm;

Automatic loading length: 2500mm;

Manual loading length: 4000mm;

Manual loading length: 1.5-15mm

Loading & Receiving System
Loading: Auto
Receiving: Automatic

Software
3rd party RIP Software

Input format
PDF, JPEG, TIFF, AI, CDR etc.

Site requirement (Min)
6910 mm(W) * 8730 mm(L) * 2500 mm(H)

Power
3Phase/380V, 100A, 50HZ, Total Power 50KW

Air Supply
Pressure ≥ 6Kg/cm²; Speed ≥ 34 liters/min

Environment
Relative humidity: 40%-60%; Temperature: 15ºC -28ºC

Measurement
4910 mm(W) x 5730 mm(L) x 1965 mm(H) (Take feeding direction as length)

Weight
7500 Kg (Feeding section included)

Model HighJet2500B
Applications

Kraft, Coated, Personalized Applications such as Display Shelf,

UV Solutions(PVC Expansion Sheet/Acrylic) etc.

Ink Type Han FullColor Water-Based Ink
Print head Industrial inkjet Kyocera print heads with piezo technology
Dryer IR & Hot air
Ink Supply Automatic
Print head Configuration

Standard: 8 printheads, double-row 4 colors (CMYK),

maximum 8 printheads

Capacity 1pass: 600sqm/hr
2pass: 300sqm/hr
Media Max. Width: 2500mm
Automatic loading length: 2500mm
Manual loading length: 4000mm
Manual loading length: 1.5-15mm
Loading & Receiving System Loading:Auto; Receiving: Automatic
Software 3rd party RIP Software
Input format PDF, JPEG, TIFF, AI, CDR etc.
Site requirement (Min) 6910 mm(W) * 8730 mm(L) * 2500 mm(H)
Power 3Phase/380V, 100A, 50HZ, Total Power 50KW
Air Supply Pressure ≥ 6Kg/cm²; Speed ≥ 34 liters/min
Environment Relative humidity: 40%-60%; Temperature: 15ºC -28ºC
Measurement

4910 mm(W) x 5730 mm(L) x 1965 mm(H)

(Take feeding direction as length)

Weight 7500 Kg (Feeding section included)









 ↘↘↘ Features

1. Multifunctional upgrade, assured application of medium productivity

2. Grayscale printing, the resolution can reach 600*2400dpi

3. Realize variable data, suitable for high-quality coated paper printing


4. No pre-coating, flexible and convenient, safe and eco-friendly.







 ↘↘↘ About Ink

We offer ink workable for this machine as below for your option. Ink is not mandatory for machine purchase.



Ink description Our offer Remarks
Water base dye ink $22/kg

Price could be better

if quantity goes up.

Water base Pigment ink $35/kg
UV ink $55/kg
White ink $60/kg



High Resolution Scanning Press Digital Inkjet Printer For Corrugated Box 0









 ↘↘↘ Producing And Packaging

From producing to delivery, we make every details very carefully to guarantee the good product quality and service to customers.



High Resolution Scanning Press Digital Inkjet Printer For Corrugated Box 1



High Resolution Scanning Press Digital Inkjet Printer For Corrugated Box 2



High Resolution Scanning Press Digital Inkjet Printer For Corrugated Box 3

High Resolution Scanning Press Digital Inkjet Printer For Corrugated Box 4

High Resolution Scanning Press Digital Inkjet Printer For Corrugated Box 5



High Resolution Scanning Press Digital Inkjet Printer For Corrugated Box 6



High Resolution Scanning Press Digital Inkjet Printer For Corrugated Box 7



High Resolution Scanning Press Digital Inkjet Printer For Corrugated Box 8









 ↘↘↘ Certificates


High Resolution Scanning Press Digital Inkjet Printer For Corrugated Box 9



High Resolution Scanning Press Digital Inkjet Printer For Corrugated Box 10









 ↘↘↘  FAQ



Q1: What are your main products ?

A: Our main products are the Prepress 4up and 8up Online/Offline Thermal CTP, CTCP, VLF CTP, Flexo CTP, Processor, Offset Plates, Offset Inks, Offset Printing Blankets, Postpress Packing Equipment and so on.

You can get the equipment and consumables all in one and no worry about the after-sales service from our company.



Q2: Where is your factory ?

A: Our CTP Processor machine factory is in Shanghai, you are warmly welcome to visit our factory!


Q3: How long is the lead time ?

A: The lead time is normally 30 days. We can accelerate for emergency cases.



Q4: Is there any certification for your machine ?

A: Yes, all our machines have been certified by SGS and CE.


Q5: How long is the warranty period ?

A: EcooGraphix guarantees 1 year of warranty for laser head and spare parts.



Q6: What is your normal payment term ?

A: Normally, 30% TT deposit, 70% before shipping, or LC at sight.



Q7: What about the installation and after-sales technician support ?

A: Our engineer can go to help the installation and provide the necessary training. The buyer should take the round air plane tickets, service charge and the local accommodation cost. Any problems or questions, we will be at your disposal 7x24 hours. Among our large amount of CTP installations worldwide, there are also many end users(printers) who have purchased the CTP products from EcooGraphix China directly and EcooGraphix technical service team support these installations remotely with regular onsite visits.



These end users printers all run the CTP systems with full satisfaction due to our robust quality, seamless remote service, thorough training and maintanence. If you are a printer who is considering purchasing directly from EcooGraphix China, there is no hassle on installations, training and after sales service. We guarantee your satisfaction.
