4/6Corner Carton Paper Box Making Machine Folder Gluer
Features of Carton Erecting Machine
1. The finished products are counted automatically by a counter device.
2. It has low load power, 5KW and 8KW. Speed adjust by inventor brings more accurate.
3. The carton erecting machine uses a PLC encoder, has high automatic function, easy to operate and adjust, and causes less fault.
Maintenance is convenient.
4. It uses a servo control system, making it more smooth, accurate, stable and with small vibration.
Product details:
◆ Automatic Production Line Suitable for Various Sky and Ground Covers
◆ Fault Diagnosis Function
◆ Function of automatic suction paper and ash board
◆ High Precision Cam Flying Paper Feeding
◆ Panasonic servo control system is adopted for the whole machine
◆ Visual positioning system and robot grasping (positioning error is less than 0.1mm)
◆ Using Yamaha Robot
◆ Using a new cycle temperature-controlled gluing system
◆ Use precise quadrangular box-holding manipulator
◆ The length of folding ear can be adjusted by using precise sliding table.
◆ Machine built-in constant temperature system (optional)
◆ Positioning by High Definition Camera.
| Model | Ecoo-LG800A |
| Paper size (max) | L800 * W600mm |
| Paper size (min ) | L150 * W100mm |
| Max cardboard size | L760 * W560mm |
| Min cardboard size |
L120 * W100mm |
| Max box size | L400 * W300 * H100mm |
| Min box size | L80 * W60 * H15mm |
| Paper thickness | 80-350g/㎡ |
| Cardboard thickness | 0.8-3mm |
| Edge folding size | 10-90mm |
| Tuin in depth | 15-80mm |
| Air pressure | 40L/min 0.8MPa |
| Working speed | 15-35 pcs/min |
| Motor power | 14kw/380v 3 phase |
| Heating power | 8kw/380v 3 phase |
| Machine weight | 4000kg |
| Machine dimension | L7600 * W3800 * H3000mm |
Shipping And Packaging
| Shipping | By sea, or as your requirement to do | |
| Packaging | By Strong Wooden Case | |
| Packaging Dimensions | Case 1 | Size: 2980mm* 1560mm* 1320mm |
| Net weight : 1500KG | ||
| Gross weight: 1600KG | ||
| Case 2 | Size:1310mm*1170mm*900mm | |
| Net weight :250KG | ||
| Gross weight:290KG | ||
