Pepress Offset Printing Platesetter Conventional UV CTP Ctcp Machine
EcooGraphix Thermal CTP (Computer To Plate) Plate making Machine is the first Prepress necessity of quick short-run offset printing. It can Output the Images on the computer to Printing CTP plate directly though the CTP machine and save the film and labor.
By the EcooGraphix CTP, the customer can get Excellent output image quality,highly reliable stability,less space occupied with more flexibility.
EcooGraphix UV800series thermal CTP are for A1 or B1 paper size newspaper or commercial printing with the output speed 16PPH to 28PPH. The CTP is operated by manual,very easy to use.
Maximum size of plate: 1,163×940mm
Features: Less manpower, high stability and perfect output quality.
UV plate and thermal plate are available for you to lower production cost.
|ECOO UV-800 Series CTP Specifications|
|Exposing Method||External Drum|
|Discrete 405nm laser diode|
|1030mm x 800mm, 2400dpi|
|Plate Sizes||Max.1130mm x 920mm
Min.400mm x 300mm
|Exposing Size||Max.1130mm x 884mm
Min.260mm x 284mm
|Media Type||positive UV-CTP/CTCP plate or high sensitive PS plate|
|Plate Thickness||0.14mm to 0.30mm|
|Repeatability||±5μm(continuous exposing for 4times or above on the same plate with a temperature of 23℃ and humidity of 60%)|
|Plate Loading||semi automatic|
|Power Supply||single phase:220AC,+ 6%,- 10%, power Consumption:4KW|
|Operation Environment||recommended:21-25℃, Max.18-26℃, humidity:40-70%|
