800-850 nm Thermal CTP Plate with 100,000 Impressions Run Length and Non-ablation Thermal-Negative Type

$3.50/㎡
Price
800-850 nm Thermal CTP Plate with 100,000 Impressions Run Length and Non-ablation Thermal-Negative Type
Features Gallery Product Description Request A Quote
Features
Specifications
Application: Commercial Printing
Long Impression: 100,000 Impressions Actual Run Length Depends On Printing Conditions
100,000 Impressions Actual Run Length Depends On Printing Conditions: 130-150 Mj/ M²
Spectral Sensitivity: 800-850 Nm
Image Color: Blue
Highlight:

800-850 nm Thermal CTP Plate

,

100

,

000 impressions Thermal CTP Plate

,

Non-ablation thermal-negative type CTP Plate
Basic Infomation
Place of Origin: China
Brand Name: EcooGraphix
Certification: ISO,CE
Model Number: ECOO-G
Payment & Shipping Terms
Packaging Details: Standard Exporting Plywood Boxes
Delivery Time: 30 DAYS
Payment Terms: T/T
Supply Ability: 200, 000 Square Meter/Year
Product Description
ECOO-G Thermal Processless CTP Plate
ECOO-G Thermal Processless Laser-Sensitive Plate is a non-ablation thermal-negative type plate engineered for high-grade commercial and newspaper printing applications, delivering up to 100,000 impressions run length.
Technical Specifications
ModelECOO-G
Plate TypeNon-ablation thermal-negative type
ApplicationHigh grade commercial and newspaper printing
SubstrateElectrolyte graining and Anodized AL substrate
Thickness0.15mm / 0.30mm
Maximum Short Grain WidthMaximum width 1280 mm
Spectrum Scope800-850 nm
Photosensitive Wave Length830 nm
Platesetter CompatibilityVarious dominant thermal platesetters in the market
Image ColorBlue
Low-energy Imaging130-150 mj/m²
Latent Image Stabilization Period≤7 days
Recommended Screen Method1-99 @200 Lpi AM / 20u FM and mixture
Start-up Paper Number<50 sheets
Safety Light1 hour under fluorescent lamp, no direct irradiation with natural light, 4 hours under yellow light
ProcessingWithout processing, directly on press
Run Length100,000 impressions (Actual run length depends on printing conditions)
Shelf Life12 months under recommended conditions
Storage Conditions18℃-24℃, 40%-50% RH
800-850 nm Thermal CTP Plate with 100,000 Impressions Run Length and Non-ablation Thermal-Negative Type 0
Complete Product Range
  • ECOO-G Thermal Chemistry-free CTP Plate, negative-working, no process required
  • ECOO-CTCP CTCP Plate
  • ECOO-ES Thermal CTP Plate, single layer, positive-working
  • ECOO-ED Thermal CTP plate, double layer, positive-working
  • ECOO-TSR Thermal CTP plate, double layer, positive-working
  • ECOO-CTCP-ES Positive CTCP Plate, single layer
  • ECOO-CTCP-D Positive UV-CTCP Plate, double layer
Ordering & Support Information
Lead Time30 calendar days from deposit confirmation
Payment Term30% deposit via T/T, 70% balance before shipment
Packaging TermExport-grade cartons with ECOO labels, custom packaging available
Shipment TermFOB, CIF, or DDU options available
Free SamplesUp to 10 sample plates available for testing
