Thermal Negative Plate For High Grade Commercial Newspaper Printing

ECOO-G Thermal DOP Plate (developed on press)

ECOO-G is well sold in Europe, USA, and Canada. It is like Kodak Sonora and Agfa Azura. It meets the trend of being environment-friendly and has a bright future. This plate can be applied on a printing machine directly without processing and developing. So it saves the cost of labor, water treatment, and developer tank.

Specification

Features

High-quality aluminum substrate and unique-grain processing technology. The substrate grain is uniformly fine, which ensures the exact dot reproduction and excellent printing adaptability of the printing plate.
The professional formula design with an infrared laser-sensitive phase-change layer ensures that the plate can be put on press directly after exposure.
High sensitivity, wide tolerance, screen dots with margin sharpness
Excellent printability, fast-inking balance, suitable for high-grade commercial and packaging printing.
Compatible with various dominant thermal platesetters in the market, suitable for manual and automatic loading systems.
Bright room operation in which people can operate safely under fluorescent lamps.
Stable quality.
A variety of plates provided with thicknesses from 0.15mm to 0.40mm.


Applications

Suitable for sheet-fed offset press or high-speed rotary offset press.

Run length: 100000 impressions
Suitable for different types of traditional inks and fountain solutions, including alcohol substitutes as fountain solutions.

Plater structure
