Non-Process Aluminum DOP Plate ECOO-G
EcooGraphix Ecoo-G is a new, environmentally friendly, Development On Press CTP plate.
It can be run directly on a printing press after imaging, without a need for chemical processing.
1. INTRODUCTION OF ECOO-G
-Run length: 100,000 impressions
-Suitable for sheet-fed offset press or high speed rotary offset press
-Suitable for different types of traditional inks and fountain solutions, including alcohol's substitutes as fountain solutions
-Unsuitable to improve run length by baking plates
Model ECOO-G
Plate Type
Thermal-negative type
Application
High grade commercial and newspaper printing
Substrate
Electrolyte graining and Anodized AL substrate
Thickness
0.15mm / 0.30mm
Maximum short grain width
Maximum width 1280 mm
Spectrum scope
800-850 nm
Photosensitive wave length
830 nm
Platesetter
Various dominant thermal platesetters in the market
Coating color
Grey
Low-energy imaging
130-150 mj/ cm²
The period of latent image stabilization
≤7 days
Recommended screen method
1-99% @200 LPI AM or 20μm FM or mixture
The paper number of start-up
<50 sheets
Safety light
4 hours under yellow light; 1 hour under fluorescent lamp;
Direct exposure under natural light is safe but not recommended.
Processing
Without processing, directly on press
Run Length
100,000 impressions Actual run length depends on printing conditions
Shelf life
12 months under recommended condition
Transportation
Packed in seal and stored by means of prevention from light, moisture, overheat and high humidity
Storage
Recommended condition: 18ºC-24ºC, 40%-50% RH.
| Model | Processless plate |
| Plate Type | Non-ablation thermal-negative type |
| Application | High grade commercial and newspaper printing |
| Substrate | Electrolyte graining and Anodized AL substrate |
| Thickness | 0.15mm / 0.30mm |
| Spectrum scope | 800-850nm |
| Platesetter | Various dominant thermal platesetters in the market |
| Low-energy imaging | 130-150 mj/ m² |
| The period of latent image stabilization | ≤7 days |
| Recommended screen method | 1-99% @200 LPI AM or 20μm FM or mixture |
| The paper number of start-up | <50 sheets |
| Safety light |
4 hours under yellow light; 1 hour under fluorescent lamp; Direct exposure under natural light is safe but not recommended. |
| Processing | Without processing, directly on press |
| Run Length | 100,000 impressions, actual run length depends on printing conditions |
| Baking | No recommended |
| Maximum short grain width | Maximum width 1280 mm |
| Photosensitive wave length | 830 nm |
| Coating color | Grey |
| Shelf life | 12 months under recommended condition |
| Transportation |
Packed in seal and stored by means of prevention from light, moisture, overheat and high humidity |
| Storage | Recommended condition: 18ºC-24ºC, 40%-50% RH. |
Comparing With The Plate Of Kodak Sonora XP
| Features | ECOO-G | Kodak Sonora XP |
| Sensitive wavelength(nm) | 800-850 | 800-850 |
| Coating color | Light green | Light green |
| Sensitivity (mj/cm2 ) | 150 | 150 |
| Exposure in safe light | White light 1 hour; yellow light 24 hours | White light 1 hour; yellow light 24 hours |
| After image contrast | Can be spotted by eyes, but auto punching machine cannot recognize it |
Can be spotted by eyes, but auto punching machine cannot recognize it |
| Imaging device | Normal thermal CTP device 1-99% @ 200lpi | Normal thermal CTP device 1-99% @ 200lpi |
| Resolution | 1-99% @ 200lpi (dependent on CTP capability) |
1-99% @ 200lpi (dependent on CTP capability) |
| Run-length | 100,000 | 100,000 |
| Storage | 12 month (under recommend environment) | 12 month (under recommend environment) |
Applied parameters In Imaging Device
| Data | Kodak trendsetters |
LOTTEM 400(TH1.7) |
MAGNUS 400 | Screen 8600S |
| Laser power | 15- 17W | 300-320mw | 19.5-21.5W | 80-90 % |
| Drum speed | 250-300rpm | 850-900rpm | 400-450rpm | 800-900rpm |
| Resolution | Customized | Customized | Customized | Customized |
| Parameter that | Focus/ | Focus/ | Focus/ | Focus/ |
| need set up | Zoom | Zoom | Zoom | Zoom |
Producing and Packing
Customer's Feedback
Workflow
FAQ
Q1: Can I get the sample?
A: We are very glad to provide some sample for you to test. We usually provide 5-15pieces plates for free,but sincerely hope to get your kind support for the air courier freight. This cost can be returned to you in your first order.
Q2: What is the cost for the CTP plate sample freight?
A: The Air freight depends on the packing size and weight, and the delivery destination. Or you can arrange the Pick-up service from your local agent.
Q3: How long can the sample be ready?
A: It usually takes about 3days to prepare the sample.
Q4: Can I visit your factory?
A: You are warmly welcomed to visit our factory! Our company is in Hangzhou city,which is about 1.5 hour by train from Shanghai.
Q5: How many Square Meters CTP plates can feed one 20' container?
A: About 20000-25000SQM
