Double Layer UV-Resistant CTCP/UV Plate- long running length, workable with UV ink
Application
With the leading double coated technology, ECOO-CTCP-D double-layered CTCP plate is specially designed for excellent resistance for UV-inks.
It delivers longer run-length and higher with lower energy required.
Features
| General Information | |
| Plate Model | ECOO-CTCP-D |
| Plate Type | Positive CTCP Plate(Double Layer) |
| Application | High quality commercial and newspaper printing |
| Substrate | Electro chemically Grained and Anodized lithographic Aluminum |
| Plate Thickness | 0.15,0.20, 0.25,0.30, 0.40 (mm) |
| Maximum short grain width | Maximum width 1280 mm |
| Length of Press Runs | Unbaked: 80000 to 100,000 impressions UV INK: About 50,000 impressions |
| Exposing | |
| Plate setters | Luscher , Basysprint, Cron or EcooGraphix UV series CTCP machine |
| Exposure energy | 50 - 70 mJ/cm² |
| Spectral Sensitivity | 400 - 410 nm - UV Laser |
| Resolution | 2 - 99% LPI 200 |
| Image color | Blue |
| Developing | |
| Developer | Any Positive plate developer or our own developer |
| Processing temperature | 23°C +/- 2°C |
| Developing time | 25 - 30 sec |
| Processing Speed | 0.80 - 1.20 m/min |
| Storage and handling | |
| Safelight | Handle under yellow safelight (UV free) |
| Shelf Life | 12 months under recommended storage conditions |
| Storage and handling | Stored in a cool and dry environment, away from excessive cold, heat and humidity. |
Producing and Packing
More details
FAQ
Q1: Can I get a sample?
A: We are very glad to provide some sample for you to test. We usually provide 5-15pieces plates for free,but sincerely hope to get your kind support for the air courier freight. This cost can ber returned to you in your first order.
Q2: What is the cost for the CTP plate sample freight?
A: The Air freight depends on the packing size and weight, and the delivery destination. Or you can arrange the Pick-up service from your local agent.
Q3: How long can the sample be ready?
A: It usually takes about 3days to prepare the sample.
Q4: Can I visit your factory?
A: You are warmly welcomed to visit our factory! Our company is in Hangzhou city,which is about 1.5 hour by train from Shanghai.
Q5: How many Square Meters CTP plates can feed one 20' container?
A: About 20000-25000SQM
Q6: Can I take my own brand and label on the packing?
A: Yes, we can provide the OEM with the customer's brand and label.
