Positive Analog PS Plate High Resolution Conventional For Offset Printing

1000SQM
MOQ
Negotiable
Price
Positive Analog PS Plate High Resolution Conventional  For Offset Printing
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Positive Analog PS Plate
Material: Electro Chemically Grained And Anodized Lithographic Aluminum
Application: Commercial And Newspaper Printing
Length Of Run: Unbaked: 50000 To 80,000 Impressions Baked: Over 100000 Impressions
Exposure Energy: 80 - 180 MJ/cm²
Resolution: 2-98% LPI 200
High Light:

Positive Analog CTP Printing Plates

,

Offset Printing Analog PS Plate

,

High Resolution Positive Ps Plate

Basic Infomation
Place of Origin: CHINA
Brand Name: EcooGraphix
Certification: CE, ISO900
Model Number: ECOO-PS
Payment & Shipping Terms
Packaging Details: Standard Exporting Wooden Box
Delivery Time: 30 days
Payment Terms: L/C, T/T
Supply Ability: 2000, 000 Sqm Per Year
Product Description

Positive Analog PS Plate





Product Description




Application:

EcooGraphix PS Plate or conventional analog plate can be used for offset/lithographic commercial and newspaper printing.
Unique production technology and high quality materials make the plate gain high photosensitive speed, good half-tone dot reproduction and stable performance.


Characteristic:


-Uniform surface coating and high photosensitive speed   -High resolution and higher press run
-Precise half-tone dot reproduction   -Faster Exposure and good stability





Specification




Model: ECOO-PS

Plate Type PS Plate

Application Commercial and newspaper printing

Substrate Electro chemically Grained and Anodized lithographic Aluminum

Gauge 0.15, 0.20, 0.25, 0.30, 0.40(mm)

Maximum short grain width Maximum width 1280 mm

Power of light 3,000 - 5,000 w

Length of Run
Unbaked: 50,000 to 100,000 impressions
Baked: Over 100,000 impressions (dependent upon image resolution, press, press chemical, ink and paper conditions).

Processor All brands or Manual

Aluminum Standard 1050 Alloy

Developing time 20-30 sec

Spectral Sensitivity 320 - 405 nm

Resolution 1-99% @ 300LPI

Image Color Green

Developer Any positive plate developer or our own developer

Processing temperature 20-25ºC

Processing Speed 0.80 - 1.20 m/min

Safelight Handle under yellow safe light(UV free)

Shelf life 12 months under recommended storage conditions

Packaging Available in all standard formats, including bulk packaging options such as APL packaging

Storage and handing Stored in a cool and dry environment, away from excessive cold, heat and humidity



General Information
Plate Model ECOO-PS
Plate Type Positive PS Plate/ Conventional Analog Plate
Application Commercial and newspaper printing
Substrate Electro chemically Grained and Anodized lithographic Aluminum
Aluminum alloy Standard 1050 Alloy
Coating Green
Gauge 0.15,0.20, 0.25,0.30, 0.40 (mm)
Maximum short grain width Maximum width 1280 mm
Length of Press Runs Unbaked: 50000 to 80,000 impressions Baked: Over 100000 impressions
Exposing
Power of light 3000 - 5000 W
Exposure energy 80 - 180 mJ/cm
Resolution 2 - 98% LPI 200
Photosensitive wave length 320 - 405nm
Developing
Processor All the kind Brands or Manual
Developer Any Positive plate developer or our own developer
Processing temperature 20 - 25°C
Developing time 20 - 30 sec
Storage and handling
Safelight Handle under yellow safelight (UV free)
Shelf Life 12 months under recommended storage conditions
Packaging Available in all standard formats, including bulk packaging options such as APL packaging
Storage and handling Stored in a cool and dry environment, away from excessive cold, heat and humidity



Positive Analog PS Plate High Resolution Conventional  For Offset Printing 0

Positive Analog PS Plate High Resolution Conventional  For Offset Printing 1



Workflow




Positive Analog PS Plate High Resolution Conventional  For Offset Printing 2



Producing and Packing




Positive Analog PS Plate High Resolution Conventional  For Offset Printing 3



Positive Analog PS Plate High Resolution Conventional  For Offset Printing 4



Positive Analog PS Plate High Resolution Conventional  For Offset Printing 5



Positive Analog PS Plate High Resolution Conventional  For Offset Printing 6





More details




Positive Analog PS Plate High Resolution Conventional  For Offset Printing 7



Positive Analog PS Plate High Resolution Conventional  For Offset Printing 8





FAQ




Q1: Can I get the sample?
A: We are very glad to provide some sample for you to test. We usually provide 5-15pieces plates for free,but sincerely hope to get your kind support for the air courier freight. This cost can be returned to you in your first order.

Q2: What is the cost for the CTP plate sample freight?
A: The Air freight depends on the packing size and weight, and the delivery destination. Or you can arrange the Pick-up service from your local agent.

Q3: How long can the sample be ready?
A: It usually takes about 3days to prepare the sample.

Q4: Can I visit your factory?
A: You are warmly welcomed to visit our factory! Our company is in Hangzhou city,which is about 1.5 hour by train from Shanghai.

Q5: How many Square Meters CTP plates can feed one 20' container?
A: About 20000-25000SQM

Q6: Can I take my own brand and label on the packing?
A: Yes, we can provide the OEM with the customer's brand and label.
