4-Color A2 Size Book Offset Printing Press Machine with UV Curing and Inline Varnish
Instructions:
ECOO JY-44 is equipped with CC-LINK technological bus module from Mitsubishi.
Double-diameter impression cylinder and transfer drum can reduce the times of sheet
take-over between print units.
The plate cylinder can be adjusted in the circumferential direction, lateral direction and
diagonal direction.
Features:
1 .The semi APC (Automatic Plate Changer) shortens the make-ready time.
2. To preset paper thickness when printing different kinds of paper. To adjust printing
pressure in every unit automatically, quickly and synchronously.
3. With non-stop feeder, piles are changed at production speed. It saves a great deal of
time when running thick paper and long version work offline.
4.It is equipped with CC-LINK technological bus module from Mitsubishi.
5. Double-diameter impression cylinder and transfer drum can reduce the times of sheet
take-over between print units.
6. The plate cylinder can be adjusted in the circumferential direction, lateral direction
and diagonal direction.
7. There are five rollers on the plate cylinder. There is an intermediate roller in alcoholic
damping system, which can eliminate the “ghost” image, achieve the quick ink-water
balance and reduce paper consumption.
8. There are 23 zones in split (staggered) ductor.
| Model | Ecoo JY 44 |
| Max. Sheet size(mm) | 660X540mm |
| Min. Sheet size(mm) | 273X393mm |
| Paper thickness | 0.06-0.6mm |
| Max.image area | 650x528mm |
| Plate size | 675x675mm |
| Blanket size | 740x680x1.9mm |
| Max.feeder pile height | 940mm |
| Max.delivery pile height | 780mm |
| Motor power | 13.2kw |
| Machine size | 7380×2550×1950mm |
| Weight | 19700kg |
MAIN CONFIGURATION:
| Description | Brand | Quantity | Origin |
| Printing roller | 3sets | China | |
| Anilox roller | Auclean/Laser | 1set | China |
| Unwind tension controller | Mitsubishi | 1set | Japan |
| Rewind tension controller | ZXTEC | 1set | China |
| Main motor | Wannan | 1set | china |
| Transducer | Mitsubishi | 2sets | Japan |
| Magnetic power brake/cluth | Ningxia | 3sets | China |
| Electromagnetic valve | Airtac | 2 set | Taiwan |
| Inverter | Schneider | 1set | Frence |
| AC Contactor | Schneider | 2pcs | France |
| Time relay | C-LIN | 1pc | China |
| Solid relay | Omron | 6pcs | Japan |
| Micro relay | Weidmiiller | 2pcs | Germany |
| Temperature Controller | Yuyao | 6pcs | China |
| Air switches | Siemens | 8pcs | Germany |
| Low pressure wiring | Schneider | All | France |
| All the bearing | NSK/CHINA | JAPAN/CHINA |
1) the PLC for this machine is Panasonic from japan, it is of long life time. As you know, the program like the heart for a person, it is very important.so this part we use the famous brand panasonic, and we could supply all- life guarantee.
And the program is made by company,it is easy to use and change.
2) Automatic oil supply system, you don`t need to oil the machine by hand, you just set it in the touch screen, for example, you could set when the machine run 2000 runs, then it will oil to the gear and spare parts automaticly.
3)The motor is wannan, and we supply the all-life change service. No matter how many years you use our machine, if
there is problem, then we could repair and change for you freely.
4) The feeder guide is from hamada machine, and it is much heavier and stronger, even machine working, it will not easy to moving around, it could keep the printing of high precision.
