Background and introduction
With the development of society and people's pursuit of product diversification, more and more products need to be labeled and customized. Label printing company and some enterprises need digital label printers to handle the short printing jobs and customerized design and some special pattern.
Ecoo Digital Label Printer meets the different needs of various customers with suitable printing costs and affordable product prices.
Technology data
| Digital Label Printing Machine | |
| Model | Ecoo-VP320 |
| Print speed | Up to 7.26 meters/min (30ft/min) |
| Print technology | 4 Color (CMYK) LED technology |
| Preparing time | 533MHz |
| Printer processor | less than 28s |
| Data port | (Standard)10BASE-T/100BASE-TX, USB2.0；(Options) internet 1000BASE-T, IEEE1284-B |
| Media width | 304mm |
| Print width | Min 210mm Max 308mm |
| Print length | Max 1200mm Min 98mm |
| Substrate types | Paper: Paper, High glossy paper,Matt paper； Film: PET, PP, PE, GHS.. |
| All of media was tested in special environment, not tested media possible can't be used | |
| Print quality | 1200x2400dpi |
| Toner supplies |
CMY-18500sheets (A4, 5% coverage rate) K-26000 sheets (A4, 5% coverage rate)；( Rated according to ISO/IEC 19798 guidelines) |
| Drum supplies | CMYK-100000 (print runs according to the operating cycle, Medium size and the direction to change) |
| Size | 1400*810*1600mm |
| Weight | Print engine:423KGS |
| Operating environment | Temperature:20℃-23℃,Humidity: 45-55% RH |
| Power supply | 110-127 VAC,50-60Hz@2800W,220-240 VAC ,50-60Hz@2800W |
| Power consumption | (AC220-240V) sleep 75W；waiting 100W；running 1100W |
| Monthly running job | Max.20000sqm (advice) |
| Warranty | 1 year (excluding high consumable parts) |
Software Features
In order to get a high quality printing, Ecoo researched and developed typical and easy a printer software for VP320C. This software has friendly interface, and easy to understand. Automatically edit jobs together, integrated with programmatic printing. PhaserMatch 5 color management system was nested to printing software. You can get best image label and finish the jobs easily
Auto web guide tension system
1 For tension adjustment of all media
2 Auto calculate the length of feeding
3 Ultrasonic detect edge of media to avoid media loading twisty
4 Avoid printing image to stretched and twisted
5 Increase the lifespam of engine
