Long Runs CTCP UV-CTP Offset Printing Plate for Newspaper Package Print
Ecoo-CTCP-D ,Long Runlength,UV ink compatible
1. Application
EcooGraphix Positive CTCP Plate(Double Layer) are made for UV based ink. It is also compatible with an ordinary ink. It is use for long run length high grade offset commercial and newspaper printing.
2. Characteristic
Features
- Positive writing CTCP (conventional) plate
- Double layers system
- Made with high grade aluminum from Europe
- Wide adaptability for different plate setter brands
- Non-ablative coating
- Run lengths up to 80,000 impressions
- UV Ink up to 50,000 impressions
- Ability to print both AM and FM screening
Advantages
- Resist UV-ink; workable with both normal ink and UV ink
- Mature product, good stability and wide processing latitude
- Long run length with non-ablative coating
- Being adaptive to most of platesetters, processors and solutions.
Benefits
- Very Quick turn around time on press
- Robust coating and consistent reliablity
- compatible with most developers
- premium quality of dot reproduction and long run length
General Information | |
Plate Model | ECOO-CTCP-D |
Plate Type | Positive CTCP Plate(Double Layer) |
Application | High quality commercial and newspaper printing |
Substrate | Electro chemically Grained and Anodized lithographic Aluminum |
Aluminum alloy | Standard 1050 Alloy |
Gauge | 0.15,0.20, 0.25,0.30, 0.40 (mm) |
Maximum short grain width | Maximum width 1280 mm |
Length of Run |
Unbaked: 80000 to 100,000 impressions UV ink: Over 50,000 impressions |
Exposing | |
Plate setters | Luscher , Basysprint, Cron or EcooGraphix UV series CTCP machine |
Exposure energy | 50 - 70 mJ/m² |
Spectral Sensitivity | 400 - 410 nm – UV Laser |
Resolution | 2 - 99% LPI 200 |
Photosensitive Wave Length | 405nm |
Coating | Magenta |
Developing | |
Processor | All the kind Brands. |
Developer | Any Positive plate developer or our own developer |
Processing temperature | 23°C +/- 2°C |
Developing time | 25 - 30 sec |
Processing Speed | 0.80 – 1.20 m/min |
Storage and handling | |
Safelight | Handle under yellow safelight (UV free) |
Shelf Life | 12 months under recommended storage conditions |
Packaging | Available in all standard formats, including bulk packaging options such as APL packaging |
Storage and handling | Stored in a cool and dry environment, away from excessive cold, heat and humidity. |
Our Production Lines
Our Partner and Customers
FAQ:
1. What are your main products ?
EcooGraphix is a leading and professional Supplier for Prepress Solution , Printing Materials and Post Packing Equipment.
Our main products are the Prepress 4up and 8up Online/Offline Thermal CTP , CTCP , VLF CTP and CTCP, Flexo CTP , Processor , Offset Plates ,inks , blankets , postpress Packing equipments and so on.
Our partners in USA,Canada,Mexico,Colombia,Turkey,Hungary,South Africa and so on are very pleased with our Technician Support service and product performance.
We can also supply the thermal CTP plate(single and double layers),positive CTCP plates(single and double layers) and Chemistry free CTP plate.
You can get the prepress equipment and consumables all in one and no worry about the after-sales service from our company.
2. Where is your factory ?
Our CTP machine factory is located in Hangzhou city , which is about 1.5 hour by train from Shanghai.
You are warmly welcomed to visit our factory!
3. What is your warranty for the CTPs ?
Three years' Laser Head and main spare parts for the CTPs, One year for the Processor.
4. What is the Lead Time?
Usually 10-30 days, and we will try our best to meet your demands.
5. Can you also supply the Workflow and RIP?
Yes, we can provide the Workflow Brain New and RIP Compose V12.
6. What about the Installation and after-sales technician support?
Our engineer can go to help the installation and provide the necessary training. The buyer should take the round air plane tickets and service charge and the local accommodation cost. Any problems or questions,we will be at your disposal 7x24 hours.
