CTP Plate Washing Machine 1500mm Max Plate Size 72L Developing Capacity

1SET
MOQ
CTP Plate Washing Machine 1500mm Max Plate Size 72L Developing Capacity
Features Gallery Product Description Request A Quote
Features
Specifications
Max.Plate Size: 280-1500mm
Developing Capacity: 72L,58L,46L
Condition: New
Machine Size: 1500x1400x1100mm
Net Weight: 350KGS
Power Supply: 220V
Warranty: One Year
Working Type: Working With Offline Or Online Thermal CTP Or CTCP
Highlight:

CTP plate washing machine 1500mm

,

CTP plate machine 72L capacity

,

plate washing machine with developing
Basic Infomation
Place of Origin: China
Brand Name: EcooGraphix
Certification: CE,SGS
Model Number: EcooGraphix P1150E,P900E
Document: Printing Plate Detention Ma...ne.pdf
Payment & Shipping Terms
Packaging Details: standard export packing
Delivery Time: 30 DAYS
Payment Terms: T/T
Supply Ability: 500SETS
Product Description
Offset Printing Plate Washing CTP Detention Machine
The printing plate retention machine is suitable for printing factories that need to reprint orders. The PS or CTP plate used during brushing automatically corrects and washes ink, washes, glues, and dries for storage and reuse. This saves plate materials and plate making time while improving work efficiency. Features advanced technology, stable performance, and durability.
Specifications:
Machine type EcooGraphix-P1500E
Page size The most wide: 1500 mm shortest: 300 mm
Plate thickness 0.15-0.4mm
Processing power Speed adjustable (10 to 60 seconds) 400-1000 mm/minutes
Temperature 10 to 45 ℃ can be adjusted (automatic temperature control, cooling system)
Developing capacity 72L
Water circulation Yes
Drying temperature 20-65 ℃ can be adjusted
Power supply 220 V (208 V-240 V) single-phase 50-60hz/6.5KW
Dimension 3720mmX2090mmX980mm (LxWxH)
Weight 600kg
Capacity 24-60m/h
Rotary Speed of Wash Brush 85-130rpm
Filter 50/100um
Water supply Tap water
Gumming Auto gumming system
Dev.heating-up rate About 0.5 ℃/minute
Horizontal adjustment adjustable
Characteristics
  • User friendly operation: Touch screen is adopted for user operation; it makes the machine more humanized.
  • Easy maintenance: Main parts are mostly located sides of machine, and they are easy to access; scales and position mark are built into the machine; it is easy to get removed parts back after maintenance.
  • Safety standard: Chemical low-level warning, drier overheat self protection, plate jam warning and cover safety protection can give warning or even stop machine for the safety purpose.
  • Robustness, reliability and consistency: PVC board tub and tough rubber roller is used in the machine. It is high resistant to acid alkali corrosion; key-slot design is adopted at processor chain and gears transmission, which makes it stronger resistance to impact.
  • Optimized plate processing path: Double chemical recycling pipes make the chemical better distributed; well designed plate path workflow curve ensures the plate processing stable and smooth through developing, washing, gluing and drying tank.
  • Unique roller design: Ensures even squeezing effect along rollers.
  • Environmental friendliness and energy saving: Optimized inner water wash circulation design can save water as high as 70% comparing with full running water wash. Heating airflow is protected by pipes, saving the energy efficiently.
CTP Plate Washing Machine 1500mm Max Plate Size 72L Developing Capacity 0
Other smaller models
Machine Type ECOO-P900E ECOO-P1150E ECOO-P1250E
Page Size 280-895 mm 280-1150 mm 290-1250 mm
Plate thickness 0.15-0.4mm 0.15-0.4mm 0.15-0.4mm
Processor Power 10-60 seconds 10-60 seconds 10-60 seconds
Temperature 10 to 45 ºC can be adjusted (automatic temperature control, cooling system)
Developing Capacity 46L 58L 70L
Drying Temperature 20-65 ºC can be adjusted
Electricity Source 220 V (210V-240 V) single-phase 50-60hz
Work Rate 4.5KW 5KW 5.5KW
Net.Weight 320kg 340kg 512kg
CTP Plate Washing Machine 1500mm Max Plate Size 72L Developing Capacity 1 CTP Plate Washing Machine 1500mm Max Plate Size 72L Developing Capacity 2 CTP Plate Washing Machine 1500mm Max Plate Size 72L Developing Capacity 3 CTP Plate Washing Machine 1500mm Max Plate Size 72L Developing Capacity 4 CTP Plate Washing Machine 1500mm Max Plate Size 72L Developing Capacity 5 CTP Plate Washing Machine 1500mm Max Plate Size 72L Developing Capacity 6
FAQ
1. What are your main products?
Our main products are the Prepress 4up and 8up Online/Offline Thermal CTP, CTCP, VLF CTP and CTCP, Flexo CTP, Processor, Offset Plates, inks, blankets, postpress Packing equipments and so on. Our partners in USA, Canada, Mexico, Colombia, Turkey, Hungary, South Africa and so on are very pleased with our Technician Support service and product performance. You can get the prepress equipment and consumables all in one and no worry about the after-sales service from our company.
2. Where is your factory?
Our CTP machine factory is located in Hangzhou city, which is about 1.5 hour by train from Shanghai. You are warmly welcomed to visit our factory!
3. What is your warranty for the CTPs?
Three years' Laser Head and main spare parts for the CTP machine, One year for the CTP Processor.
4. What is the Lead Time?
Usually 10-30 days, and we will try our best to meet your demands.
5. Can you also supply the Workflow and RIP?
Yes, we can provide the Workflow Brain New and RIP Compose V12.
6. What about the Installation and after-sales technician support?
Our engineer can go to help the installation and provide the necessary training. The buyer should take the round air plane tickets and service charge and the local accommodation cost. Any problems or questions, we will be at your disposal 7x24 hours.
