Home /Products/CTP Plate Machine/Thermal Computer To Plate Making CTP Machine 2400dpi

Thermal Computer To Plate Making CTP Machine 2400dpi

1SET
MOQ
Negotiable
Price
Thermal Computer To Plate Making CTP Machine 2400dpi
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Computer To Plate Making Machine
Exposing Mothod: External Drum
Plate Sizes: Max.800mm X 660mm Min. 400mm X 300mm
Plate Thickness: 0.15mm To 0.30mm
Resolution: 2400dpi
Machine Size: 1900x1200x1000(WxLxH)mm
Highlight:

2400dpi CTP Plate Machine

,

Computer To Plate Making CTP Machine

,

Thermal CTP Plate Machine
Basic Infomation
Place of Origin: CHINA
Brand Name: EcooGraphix
Certification: CE, ISO900
Model Number: Ecoosetter T-400
Payment & Shipping Terms
Packaging Details: Standard Exporting Wooden Box
Delivery Time: 30days
Payment Terms: L/C, T/T
Supply Ability: 1000 SETS/YEAR
Product Description

Product Description

Product Description
Thermal Computer To Plate Making CTP Machine 2400dpi 0
The EcooGraphix Thermal CTP T-400 Series is one of our most popular and best-selling models, widely favored by small to mid-sized printing companies. As an essential prepress solution for quick, short-run offset printing, the T-400 Series directly transfers digital images from the computer to CTP plates—eliminating the need for film and significantly reducing labor and production costs. It offers a reliable, efficient, and cost-effective way to streamline your printing workflow.
Specification



EcooGraphix T-400 Series Thermal CTP Specifications
Model T-400F T-400S T-400E
Imaging System 48 channel 32 channel 24 channel
Output Speed 28pph 22pph 16pph
800mm x 600mm / 2400dpi
Plate Size Max. 800 x 690mm Min. 400mm x 300mm
Plate Thickness 0.15mm to 0.30mm
Resolution 2400dpi
Weight 800KG
Repeatability ±5μm(continuous exposing for 4times or above on the same plate with a temperature of 23ºC and humidity of 60%)
Machine Size (WxLxH)mm 1900×1200×1000mm(W×D×H)
Power Supply single-phase: 260AC, +6%-10%; Power Conumption: 4KW
Environment recommended: 21-25ºC, Allowed temperature:15-30ºC, Humidity: 40-70%RH
Features



Compact footprint for flexible installation

Space-saving design with high stability and excellent output quality

Multiple speed settings to meet varying production demands


Tag:

offset printing ctp machine

offset printing ctp plate machine

automatic computer to plate machine
