Name: Max.1130mm x 920mm Min.400mm x 300mm CTP Plate Processors Wide Format Developing Machine
Brand: Hangzhou Ecoographix Digital Technology Co., Ltd.
SKU: Ecoo Processors
Price: 150000.00 USD
Availability: InStock

Max.1130mm x 920mm Min.400mm x 300mm CTP Plate Processors Wide Format Developing Machine

1SET

MOQ

Negotiable

Price

Features Gallery Product Description Request A Quote

Features

Specifications

Product Name: CTP Plate Processor

Plate Thickness: 0.15-0.4mm

Plate Sizes: Max.1130mm X 920mm Min.400mm X 300mm

Processing Speed: Speed Adjustable (10 To 60 Seconds) 400-2400 Mm/minute

Developing Capacity: 46/58/70/78L

Drying Temperature: 20-65°C Can Be Adjusted

Electricity Requirement: 220V (208 V-240V) Single-phase 50 Or 60hz

Highlight:

1130mm CTP Plate Processors

920mm CTP Plate Processors

400mm CTP Plate Processors

Basic Infomation

Place of Origin: CHINA

Brand Name: EcooGraphix

Certification: CE, ISO900

Model Number: Ecoo Processors

Payment & Shipping Terms

Packaging Details: Standard Exporting Wooden Box

Delivery Time: 20-30 days

Payment Terms: L/C, T/T

Supply Ability: 5000 SETS/YEAR

Gallery

Max.1130mm x 920mm Min.400mm x 300mm CTP Plate Processors Wide Format Developing Machine

Product Description

Seepd Adjustable Developing Machine CTP Plate Processors

Max.1130mm x 920mm Min.400mm x 300mm CTP Plate Processors Wide Format Developing Machine 0

Application

After exposing PS or CTP plates, a processing machine is crucial for further development. The EcooGraphix CTP Processor is a versatile tool compatible with various Thermal, CTCP, or UV-CTP platesetters from brands like Kodak, Screen, Agfa, Creo, Amsky, and Cron, ensuring efficient plate processing and quick turnaround.

Characteristics

The machine is designed for ease of use and maintenance, adhering to safety standards. It offers a robust and reliable processing path with a unique roller system. Additionally, it is energy-efficient and environmentally friendly, making it an excellent choice for any printing requirements.

Specifications

Ecoo Processors Series
Model	*P-900*	*P-1150*	*P-1250*	*P-1500*
Page Size	280-860 mm	280-1100 mm	280-1200 mm	290-1500 mm
Plate Thickness	0.15-0.4mm
Processing Speed	Speed adjustable(10 - 60 seconds) 400 - 1000mm/minute
Temperature	10 to 45 ºC can be adjusted (automatic temperature control, cooling system)
Developing Capacity	46L	58L	70L	78L
Drying Temperature	20-65 ºC can be adjusted
Electricity Requirement	220 V (208 V - 240 V) single-phase 50-60hz
Working Power	4.5KW	5KW	5.5KW	6.5KW
Weight	355kg	420kg	512kg	600kg
Machine Size	1420 x 1460 x 1280mm

Max.1130mm x 920mm Min.400mm x 300mm CTP Plate Processors Wide Format Developing Machine 1
