Name: T-800 28PPH Precision Thermal CTP Plate Makeing Machine
Brand: Hangzhou Ecoographix Digital Technology Co., Ltd.
SKU: ECOO T-800(E, S, F) A
Price: 150000.00 USD
Availability: InStock

Features Gallery Product Description Request A Quote

Features

Specifications

Media Type: Positive Thermal CTP Plate

Machine Size (Wxlxh)mm: 2127 X 1610 X 1058

Imaging System (Channel): 64CH/ 48CH/ 32CH, Discrete 830nm Laser Diode

Throughput (Plates/Hour): 28pph/ 22pph/ 16pph, 1030mm X 800mm, 2400dpi

Plate Thickness: 0.15mm To 0.30mm

Resolution: 2400dpi(Option: 1200dpi)

Repeatability: ±5μm(Continuous Exposing For 4 Times Or Above On The Same Plate With A Temperature Of 23℃ And Humidity Of 60%)

Environment Recommended: Recommended: 21-25℃, Max. 15-30℃, Humidity: 40-70%

Highlight:

2400dpi CTP Plate Machine

Automatic Thermal CTP Plate Machine

28PPH CTP Plate Machine

Basic Infomation

Place of Origin: China

Brand Name: EcooGraphix

Certification: ISO9000, CE

Model Number: ECOO T-800(E, S, F) A

Payment & Shipping Terms

Packaging Details: Standard Export Packing

Delivery Time: 45 Days

Payment Terms: L/C, T/T

Supply Ability: 10,000 Sets/Year

Gallery

T-800 28PPH Precision Thermal CTP Plate Makeing Machine

Product Description

16-28PPH Automatic Online Platesetter Thermal CTP Machine

Application

EcooGraphix Thermal CTP (Computer To Plate) Plate Making Machine is an essential prepress solution for quick short-run offset printing. This machine directly transfers computer images to printing CTP plates, eliminating the need for film and reducing labor costs.

With the EcooGraphix CTP, customers benefit from excellent output image quality, highly reliable stability, and a compact design that offers greater flexibility.

The EcooGraphix T800 series Thermal CTP is designed for A1 or B1 paper-size newspaper or commercial printing, with an output speed ranging from 16PPH to 28PPH. The machine operates manually, making it very user-friendly and easy to use.

Specification

ECOO T-800 Series Automatic CTP Specifications(online system)
Model	T-800FA	T-800SA	T-800EA
Exposing Method	External Drum
Imaging System	64-channel	48-channel	32-channel
	Discrete 830nm laser diode
Throughput	28PPH	22PPH	16PPH
	1030mm x 800mm, 2400dpi
Plate Sizes	Max. 1163mm x 940mm Min. 300mm x 400mm (300mm x 250mm is available)
Exposing Size	Max. 1130mm x 884mm
Media Type	Positive thermal CTP plate
Plate Thickness	0.15mm to 0.30mm
Resolution	2400dpi (Option: 1200dpi)
Repeatability	±5μm(Continuous exposing for 4 times or above on the same plate with a temperature of 23ºC and humidity of 60%)
Interface	USB 2.0
Plate Loading	Semi automatic
Net Weight	1200kg
Machine Size (WxLxH)mm	2127 x 1610 x 1058
Power Supply	Single phase: 220AC, +6%, -10%, Power Consumption: 4KW
Environment	Recommended: 21-25ºC, Max. 15-30ºC, Humidity: 40-70%
