EcooGraphix Automation Temperature Control CTP Plate Processor

1 set
MOQ
Negotiable
Price
EcooGraphix Automation Temperature Control CTP Plate Processor
Features Gallery Product Description Request A Quote
Features
Specifications
Min Width: 280mm In Width
Plate Thickness: 0.15-0.4mm
Processing Speed: Adjustable, 400-1000 Mm/miniute
Temperature: 10-45 Degree
Automatic Level: High Automatic
Electricity: 220v Single Phase 50-60 Hz
Feeding Style: Manually, Or Automatically With A Bridge
Format: Depend On The CTP Machine Format
Highlight:

Automation Temperature Control CTP Plate Processor

,

CTP Plate Processor

,

EcooGraphix CTP Plate Processor
Basic Infomation
Place of Origin: China
Brand Name: EcooGraphix
Certification: ISO, CE
Model Number: ECOO PROCESSOR SERIES
Payment & Shipping Terms
Packaging Details: wooden case
Delivery Time: 30 DAYS
Payment Terms: T/T
Supply Ability: 2000 set per year
Product Description

ECOO Processor series machine to developer CTP plate after imaging



The ECOO Processor series comprises machines tailored to three formats: P900, P1150, and P1500, designed to complement our various sizes of CTP machines. These processors are essential for thermal or CTCP plates after imaging. However, if you're using processless plates, a processor is unnecessary.

The machine operates in conjunction with developer chemistry. The imaged plate is fed into the inlet area, where it passes through the rolls immersed in the developer liquid. This process removes the unimaged area, dries the plate, and finally exits through the outlet. For detailed specifications, refer to the machine documentation below:


Specfications


ECOO Processor Series Specifications
Machine Type ECOO-P900 ECOO-P1150 ECOO-P1500
Page Size 280-895 mm 280-1150 mm 290-1500 mm
Plate thickness 0.15-0.4mm 0.15-0.4mm 0.15-0.4mm
Processor Power 10-60 seconds 10-60 seconds 10-60 seconds
Temperature 10 to 45 ºC can be adjusted (automatic temperature control, cooling system)
Developing Capacity 46L 58L 76L
Drying Temperature 20-65 ºC can be adjusted
Electricity Source 220 V (210V-240 V)single-phase50-60hz
Work Rate 4.5KW 5KW 7.5KW
Net.Weight 320kg 340kg 800kg
Matched CTP T400, UV400, T800,UV800,T400Q T800A, UV800A,T800Q T1600S, T1600M, UV1600S,UV1600M



Features



1. Robustness, Reliability, and Consistency: Engineered for long-lasting performance and dependable operation.
2. Optimized Plate Processing Path: Streamlined processing ensures efficiency and high-quality results.
3. Unique Roller Design: Innovative roller technology enhances performance and durability.
4. Environmentally Friendly and Energy Saving: Designed to minimize environmental impact and reduce energy consumption.
5. User-Friendly Operation: Intuitive interface and controls make the equipment easy to use.
6. Easy Maintenance: Simplified maintenance procedures ensure minimal downtime.
7. High Safety Standards: Built to comply with rigorous safety regulations to protect users.
