High-Speed Thermal CTP Plate Machine with 256 Channels for Commercial Printing Needs

1 set
MOQ
Negotiable
Price
High-Speed Thermal CTP Plate Machine with 256 Channels for Commercial Printing Needs
Features Gallery Product Description Request A Quote
Features
Specifications
Laser Wavelength: 830 Nm
Imaging System: 256 Diode
Throughput: 35/45/55 Pph Depending On Customer Setting
Max. Plate Size: 1130mm*920mm
Min. Plate Size: 510mm*400mm
Plate Application: Thermal Plate Thickness Between 0.15-0.40mm
Warranty: 3 Years Including All Parts
Installation: Free Installation
Highlight:

256 Channels CTP Plate Machine

,

Commercial Printing CTP Plate Machine
Basic Infomation
Place of Origin: China
Brand Name: ECOOGRAPHIX
Certification: ISO, CE
Model Number: T 800Q
Payment & Shipping Terms
Packaging Details: sea worthy exporting package
Delivery Time: 30-40 days
Payment Terms: L/C, T/T
Product Description

Super-Fast Thermal CTP equipment with 256 Diodes and online autoloader



Application:

The EcooGraphix Thermal CTP (Computer To Plate) Plate Making Machine is essential for quick short-run offset printing. It directly outputs computer images to printing plates, saving both film and labor. With excellent output image quality, highly reliable stability, and compact design, it offers flexibility while occupying minimal space. The EcooGraphix T800A series is designed for A2 or B2 paper-size newspapers or commercial printing, with output speeds ranging from 16PPH to 28PPH. Easy to operate manually, it provides user-friendly functional

Configurations:
Model EcooSetter T-800 Q Weight 2000 kgs
Image system 256 channels Size 2018mm*2701mm*1180mm
Throughput 55 plates per hour Power Supply Single phase:220AC, +6%, -10%, Power consumption:4kw
Repeatability ±5μm Environment Recommended:21-25ºC, max:18-26ºC, humidity:40-70%
Plate thickness 0.15mm to 0.3mm Laser type semiconductor laser
Resolutions 2400 dpi Laser wavelength 825nm
Plate size(max) 1163 mm*940mm Plate size (min) 400mm*300mm
Plate loading Highly automatic Brand Ecoographix or OEM


3-speed settings for this model

models and speed T800 QF T800 QS T800 QE
  55 PPH 45PPH 35 PPH


Outstanding features

RIP imaging system with 256 laser diodes makes the plate-making performance stable and high-speed.
The linear motor drive also has extremely stable operation and high positioning accuracy, providing the guarantee for high precision and accurate printing.
Equipped with automatic plate loading and unloading, and automatic feeding and punching functions, it can work continuously without any interruption to maximize performance.
Use digital square screen imaging to reduce image loss and significantly increase the printing resistance.


Delivery & Package
Any kind of transportation is workable for us. The nearest departure port is Shanghai Port or Ningbo Port.
The equipment is packed in standard wood cartons for export use with enough protective layers.
