The larger format of the printing plate used in large-format printing equipment, the more graphic information it contains, and the more times the CTP equipment needs to be exposed. Under the condition that the output resolution remains unchanged, the frequency requirements are higher.
When choosing a matching CTP for large-format printing equipment, the factors to be considered focus on the following two points:
First of all, for thermal CTP equipment, to check the hardware components and processing procedures of the format is very important, we must also pay more attention to the maximum laser output energy of the thermal imaging head.
In addition to focusing on quality, printing companies also needs to take highly of the efficiency.How to comprehensively improve the efficiency of CTP machine under the situation of stable quality and saturated customer orders has become the key.
Characteristic
Maximum size of plate: 1,880×1370mm
Features: Super Fast Output speed up to 24PPH ,Less manpower, high stability and perfect output quality.
Automatic Plate loading and unloading improves your plate-making efficiency.
Equipped with 256CH screen square dot imaging technology, its ultra-large format model is one of the fastest fully automatic platesetters on the market, combining fast, automated, and high-quality imaging features
2540dpi with optional inline punching
Other similar models
| EcooGraphix VLF(Very Large Format) CTP Series Specifications |
| Model |
UV-1600S |
UV-1600SX |
T-1600S |
UV-1600M |
UV-1600MX |
T-1600M |
| Exposing Mothod |
External Drum |
| Imaging System |
64-channel |
128-channel |
64-channel |
64-channel |
128-channel |
64-channel |
Discrete 400-410nm
laser diode |
Discrete 400-410nm
laser diode |
Discrete 830nm
laser diode |
Discrete 400-410nm
laser diode |
Discrete 400-410nm
laser diode |
Discrete 830nm
laser diode |
| Output Speed |
16plates/hour |
27plates/hour |
16plates/hour |
10plates/hour |
18plates/hour |
10plates/hour |
| |
1470mm x1180mm /2400dpi |
1630mm x 1325mm / 2400dpi |
| Plate Sizes |
Max.1470mm x1180mm;
Min. 650mm x 550mm |
Max.1680mm x1350mm;
Min. 650mm x 550mm |
| Exposing Size |
Max. 1454mm x 1164mm |
Max. 1680mm x 1336mm |
| Media Type |
positive UV-CTP plate |
positive thermal CTP plate |
positive UV-CTP plate |
positive thermal CTP plate |
positive UV-CTP plate |
positive thermal CTP plate |
| Plate Thickness |
0.15mm to 0.30mm or 0.27mm to 0.40mm(alternative) |
| Resolution |
2400dpi |
| Repeatablity |
±5μm(continuous exposing for 4times or above on the same plate with a temperature of 23ºC and humidity of 60%) |
| Interface |
USB 2.0 or USB3.0(USB2.0 is recommended) |
| Plate Loading |
semi automatic(alternative autoloader system) |
| Net Weight |
2600kg |
1800kg |
Machine Size
(WxLxH)mm |
2355x1910x1217 |
2400x1430x1110 |
| Power Supply |
single phase:220V-240V, power Consumption(peak value):5.5KW |
| |
recommended temprature:21-25ºC;allowed temperature :15-30ºC, humidity:<70%RH
|
Advantages of inline punching unit of VLF CTP machine
The registration in large-format plate making is very important. Most large-format CTPs have built-in online punching devices. In this way, after the plate enters the CTP, the online punching device will immediately perform positioning and punching. With the help of positioning holes and positioning pins, extremely high printing sets can be easily achieved.
Accurate registration reduces exposure errors caused by incorrect positioning of the printing plate;
Compared with a variety of other stand alone punching components, the output printing plate can be directly printed on the machine without manual punching, significantly shortening the printing process preparation time, greatly improving overall production efficiency.
5. Producing and Packing
From producing to delivery,we make every details very carefully to guarantee the good product quality and service to customers .
Our Partners
FAQ:
Q:What is the production time ?
A: Usually 20days, a little longer for customized model.
Q: What is the warranty time for the machine?
A: 3years’warranty for CTP machine. If customer use EcooGraphix CTP plate, all the CTP parts will be guaranteed for lifetime with no service charge.
Q:What is the payment term?
A:Normally 30% deposit,70% before shipment by T/T or LC. Other terms are negotiable.
Q:What supporting device should we prepare before installation?
A: Truck fork should be 1.5Ton or above capacity, 1.2m or longer arm;
single phase power supply,UPS,2units power supply,air compressor and so on.
Q:What about the Installation and after-sales technician support?
A:Our engineer can go to help the installation and provide the necessary training. The buyer
should take the round air plane tickets and service charge and the local accommodation cost.
Any problems or questions,we will be at your disposal 7x24 hours.
