ECOO T-800 XA Automatic CTP Specification
| Model | T-800XA |
| Exposing Method | External Drum |
| Imaging System | 256-channel |
| Discrete 830nm laser diode | |
|
Throughput |
40PPH |
| 1030mm x 800mm, 2400dpi | |
| Plate Sizes | Max.1130mm x 920mm Min.300mm x 300mm(300mmx250mm is available) |
| Exposing Size | Max.1130mm x 884mm |
| Media Type | positive thermal CTP plate |
| Plate Thickness | 0.14mm to 0.30mm |
| Resolution | 2400dpi |
| Repeatablity | ±5μm(continuous exposing for 4times or above on the same plate with a temperature of 23℃ and humidity of 60%) |
| Interface | USB 2.0 |
| Plate Loading | semi automatic |
| Net Weight | 1200kg |
| Machine Size (WxLxH)mm |
2127x1405x1058 |
| Power Supply | single phase:220AC,+ 6%,- 10%, power Consumption:4KW |
| Environment | recommended:21-25℃, Max.18-26℃, humidity:40-70% |
Outstanding features:
*Brand-new imaging technology, square-spot, the similar light-valve system as Kodak machine has, enable the imaging qualified for 20-10 micro FM screening.
* Significant improvement on speed. There are 3 new speed for option: 30 pcs per hour, 40 pcs per hour, 50 pcs per hour.
Delivery & Package
Any kinds of transpotation is workable for us. The nearest departure port is Shanghai port or Ningbo Port.
The equipment is packed in standard wood carton for exporting use with enough protective layers.
