Home /Products/CTP Plate Machine/ECOO UV-400Q Series Automatic CTP Machine with 48-channel Imaging System 30PPH Throughput and Max.800mm x 660mm Plate Size

ECOO UV-400Q Series Automatic CTP Machine with 48-channel Imaging System 30PPH Throughput and Max.800mm x 660mm Plate Size

1pcs
MOQ
$48000pcs
Price
ECOO UV-400Q Series Automatic CTP Machine with 48-channel Imaging System 30PPH Throughput and Max.800mm x 660mm Plate Size
Features Gallery Product Description Request A Quote
Features
Specifications
Punching: Automatic Punching
Plate Size: Max.800mm X 660mm Min.300mm X 300mm
Sea Port: Shanghai/ Ningbo
Highlight:

Offset Printing Plate Making Machine

,

Plate Prepress Making Machine

,

Thermal Plate Making Machine
Basic Infomation
Place of Origin: China
Brand Name: EcooGraphix
Certification: ISO,CE
Model Number: T-400Q
Payment & Shipping Terms
Packaging Details: Export Stdandard Packaging
Delivery Time: 30 DAYS
Payment Terms: T/T
Supply Ability: 1000pcs per year
Product Description
ECOO UV-400Q Series Automatic CTP Machine
Product Specifications
Model UV-400QF UV-400QS UV-400QE
Exposing Method External Drum
Imaging System 48-channel 32-channel 24-channel
Laser Type Discrete 400-410nm laser diode
Throughput 30PPH 25PPH 18PPH
Plate Size Max.800mm x 660mm
Min.235mm x 335mm
Media Type UV-CTP plate, high-sensitive PS plate
Plate Thickness 0.15mm to 0.30mm
Resolution Standard: 2400 dpi or 1200 dpi (Optional)
Repeatability 0.01mm
Interface Optical Fiber (Fiber-way)
Plate Loading Automatic or Manual
Net Weight 1100kg
Machine Size (WxLxH)mm 1450x1350x1290
Power Supply Single phase: 220AC, +6%, -10%, power consumption: 4KW
Environment Recommended: 21-25℃, Max.18-26℃, humidity: 40-70%
Key Features
  • High-precision external drum imaging system
  • Multiple channel configurations for different production needs
  • Advanced 400-410nm laser diode technology
  • Flexible plate handling with automatic or manual loading options
  • Wide compatibility with UV-CTP and high-sensitive PS plates
  • Precision repeatability of 0.01mm for consistent results
Our Worldwide Partners

ECOO collaborates with industry leaders across global markets to deliver reliable CTP solutions.

Tag:

offset printing ctp machine

offset printing ctp plate machine

automatic computer to plate machine
