Lithographic Printing CTP Plate Making Machine Conventional

1 pcs

MOQ

$33000/pcs

Price

Lithographic Printing CTP Plate Making Machine Conventional

Features Gallery Product Description Request A Quote

Features

Specifications

Laser Channel: 24-Channel

Throughput: 16 Plates/Hour

Plate Size: Max. 800*660mm, Min. 260*300mm

Resolution: 2400dpi

Sea Port: Shanghai/ Ningbo

Highlight:

Conventional Plate Making Machine

,

Conventional CTP Plate Making Machine

,

Lithographic Plate Making Machine

Basic Infomation

Place of Origin: China

Brand Name: EcooGraphix

Certification: ISO,CE

Model Number: UV-400

Payment & Shipping Terms

Packaging Details: Standard Exporting Plywood Boxes

Delivery Time: 35 days

Payment Terms: L/C, T/T, Western Union

Supply Ability: 1000pcs per year

Gallery

Lithographic Printing CTP Plate Making Machine Conventional

Product Description

EcooGraphix UV Series UV-400 Specifications

EcooGraphix UV Series UV-400 Specifications
Model	UV-400F	UV-400S	UV-400E
Exposing Method	External Drum
Imaging System	48-channel	32-channel	24-channel
	Discrete 405nm laser diode
Throughput	28plates/hour	22plates/hour	16plates/hour
	800mm x 660mm ,2400dpi
Plate Sizes	Max.800mm x 660mm Min. 260mm x 300mm
Exposing Size	Max.800mm x 646mm Min. 260mm x 284mm
Media Type	positive UV-CTP/CTCP plate or high sensitive PS plate
Plate Thickness	0.14mm to 0.30mm
Resolution	2400dpi
Repeatability	±5μm(continuous exposing for 4times or above on the same plate with a temperature of 23℃ and humidity of 60%)
Interface	USB 2.0
Plate Loading	semi automatic
Net Weight	800kg
Machine Size (WxLxH)mm	1900x1200x1000
Power Supply	single phase:220AC,+ 6%,- 10%, power Consumption:4KW
Environment	recommended:21-25℃, Max.18-26℃, humidity:40-70%
