8UP Plate Making Machine Platesetter Automatic Thermal CTP For Offset Printing
Model: 800 series
EcooSetter Auto 800 series is the first Prepress necessity of quick short-run offset printing.
It can output the images on the computer to printing CTP plate directly though the CTP machine and save the film and labor.
Features:
Robust design and manufacturing features, combine with long-lasting components!
EcooSetter Auto 800 series are characterized by their reliability, durability and low maintenance.
Engineering features that contribute to their speed, high performance and low cost of ownership.
Option 1:
No autoloader/single cassette autoloader/multi-cassette autoloader
Option 2:
2400 dpi or 2540 dpi;
Option 3:
Inline punching system, or no punch
Specification:
| Model | T-800F | T-800S | T-800E |
| Exposing Method | External Drum | ||
| Imaging System | 64-channel | 48-channel | 32-channel |
| Discrete 830nm laser diode | |||
|
Throughput |
28plates/hour | 22plates/hour | 16plates/hour |
| 1030mm x 800mm, 2400dpi | |||
| Plate Sizes | Max.1163mm x 940mm; Min.400mm x 300mm | ||
| Exposing Size | Max.1130mm x 884mm; Min.260mm x 284mm | ||
| Media Type | Positive 830nm thermal CTP plate | ||
| Plate Thickness | 0.15mm to 0.30mm | ||
| Resolution | 2400dpi | ||
| Interface | USB 2.0 | ||
| Plate Loading | Semi automatic | ||
| Net Weight | 900kg | ||
| Machine Size | 2320x1080x960 (WxLxH)mm | ||
| Power Supply | Single phase: 220AC, + 6%, - 10%, Power Consumption: 4KW | ||
| Operation Environment | Recommended: 21-25℃, Max.15-30℃, Humidity: 40-70% | ||
FAQ:
1. What is your warranty for the CTPs?
Three years' Laser Head and main spare parts for the CTP, one year for the processor.
2. Can you also supply the Workflow and RIP?
Yes, we can provide the Workflow Brain New and RIP Compose V9.
3. What about the Installation and after-sales technician support?
Our engineer can go to help the installation and provide the necessary training. The buyer should take the round air plane tickets and service charge and the local accommodation cost. Any problems or questions, we will be at your disposal 7x24 hours.
