Home /Products/CTP Plate Machine/Printing Plate Developing Machine CTP Plate Processor For Kodak Agfa Cron Amsky CTP

Printing Plate Developing Machine CTP Plate Processor For Kodak Agfa Cron Amsky CTP

1SET
MOQ
Negotiable
Price
Printing Plate Developing Machine CTP Plate Processor For Kodak Agfa Cron Amsky CTP
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Printing Plate Developing Machine CTP Processor For Kodak Agfa Cron Amsky CTP
Plate Sizes: Max Width: 1100mm Min Lenght: 280mm
Plate Thickness: 0.15-0.4mm
Developing Capacity: 58L
Processing Speed: Speed Adjustable (10 To 60 Seconds) 400-2400 Mm/minute
Drying Temperature: 20-65°C Can Be Adjusted
Electricity Requirement: 220V (208 V-240V) Single-phase 50 Or 60hz
Working Power: 5KW
Weight: 340kg
Highlight:

CTP Plate Processor Machine

,

CTP Printing Plate Developing Machine

,

5KW CTP Plate Processor
Basic Infomation
Place of Origin: CHINA
Brand Name: EcooGraphix
Certification: CE
Model Number: EcooSetter P-1150
Payment & Shipping Terms
Packaging Details: Standard Exporting Wooden Box
Delivery Time: 20-30 days
Payment Terms: L/C, T/T
Supply Ability: 500 SETS/YEAR
Product Description

Printing Plate Developing Machine CTP Processor For Kodak Agfa Cron Amsky CTP

Ecoo processor with 5 different width for specific plate size



Configurations



Ecoo Processors Series
Model P-900 P-1150 P-1250 P-1350 P-1500
Page Size(mm) Max width: 870
Min length: 280 		Max width: 1100
Min length: 280		 Max width: 1200
Min length: 280		 Max width: 1300
Min length: 290		 Max width: 1500
Min length: 300
Plate Thickness 0.15-0.4mm
Processing Speed Speed adjustable(10 - 60 seconds) 400 - 2400 mm/minute
Temperature 10 to 45 ºC can be adjusted (automatic temperature control, cooling system)
Developing Capacity 46L 58L 70L 74L 78L
Drying Temperature 20-65 ºC can be adjusted
Electricity Requirement 220 V (208 V - 240 V) single-phase 50 or 60hz
Working Power 4.5KW 5KW 5.5KW 5.5KW 6.5KW
Weight 320kg 340kg 360kg 440kg 600kg





Model: P-1150

Page Size:
280-1100 mm

Plate Thickness:
0.15-0.4mm

Processing Speed:
Speed adjustable (10 - 60 seconds) 400 - 2400mm/minute

Temperature:
10 to 45 ºC can be adjusted (automatic temperature control, cooling system)

Developing Capacity:
58L

Drying Temperature:
20-65 ºC can be adjusted

Electricity Requirement:
220 V (208 V - 240 V) single-phase 50-60hz

Working Power:
5KW

Weight:
340kg


Printing Plate Developing Machine CTP Plate Processor For Kodak Agfa Cron Amsky CTP 0


Printing Plate Developing Machine CTP Plate Processor For Kodak Agfa Cron Amsky CTP 1


Printing Plate Developing Machine CTP Plate Processor For Kodak Agfa Cron Amsky CTP 2



Delivery & Package

Any kinds of transpotation is workable for us. The nearest departure port is Shanghai port or Ningbo Port.
The equipment is packed in standard wood carton for exporting use with enough protective layers.

Printing Plate Developing Machine CTP Plate Processor For Kodak Agfa Cron Amsky CTP 3


Printing Plate Developing Machine CTP Plate Processor For Kodak Agfa Cron Amsky CTP 4

Q&A

1. How long is the lead time?
The lead time is normally 30 days. For some emergency case, we can accelarate it up to 20 days.

2. How long is the warranty period?
Ecoographix gurantees 1 year of warranty for processor machine. Anyway, it is a mature and stable machine.

3. Do you have accompanying plate products to realize an easy purchase for some end users?
Yes, we have varified CTP/CTCP plates at most competitive price. In addition, blanket, ink, developer, processors are also in our business range.

4. Payment term?
Normally, 30% deposit, 70% before shipping.

5. What about the Installation and after-sales technician support?
Our engineer are all English speakers and can go to help the installation and provide the necessary training. The buyer should take the round air plane tickets and service charge and the local accommodation cost. Any problems or questions, we will be at your disposal 7x24 hours.
