Digital Enhancement Inkjet Digital Printer With UV Varnish And Foil Stamping

1SET
MOQ
Negotiable
Price
Digital Enhancement Inkjet Digital Printer With UV Varnish And Foil Stamping
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Digital Printing Enhancement Equipment
Polymer Layer Thickness: From 10 Up To 250 Microns
Printing Speed: 6m/Min - 50m/Min(Depend On Polymer Layer Thickness
Substrates Thickness: 30-400 Micro
Substrates Width: Max 330mm
Curing Method: Inter UV-LED Pre-Curing/Full Curing By UV-LED
Printing Image Width: 288mm (Extendable To 330 Mm)
Polymer: Wb-Ds-Clear Polymer
Substrate: Offset, Digital, Plastics, Laminated And Coated Substrates
Resolution: 360*360 Dpi, Up To 1440*360 Dpi
Specification: 3500mm*1900mm*1800mm (LxHxW)
High Light:

Digital Enhancement Inkjet Digital Printer

,

UV Varnish Inkjet Digital Printer

,

Foil Stamping Label Offset Printing Machine

Basic Infomation
Place of Origin: CHINA
Brand Name: EcooGraphix
Certification: EcooSpark
Model Number: EcooSpark
Payment & Shipping Terms
Packaging Details: Standard Exporting Wooden Box
Payment Terms: L/C, T/T
Supply Ability: 500 Sets Per Year
Product Description

Digital Label Foil Stamping and Varnishing Printing Machine



EcooGraphix's newly developed EcooSpark digital printing machine realizes digital synergistic processes such as digital varnishing, 3D crystal bright, partial glazing, cold foil stamping, embossing, etc., without the need for plate making. lt can reduce costs and instantly realize unique visual effects of printing. This is a digital post-press equipment thatcreates new profit points for users, and is a digital efficiency-enhancing printing machine.
Applications: Wine Labels, Cosmetic Labels, Luxury labels and so on.

Digital Enhancement Inkjet Digital Printer With UV Varnish And Foil Stamping 0




Specification





Model EcooSpark
Printing Technology UV Piezo DoD-inkjet
Resolution up to 1080*360 dpi
Printing speed 6m/min - 30m/min(depend on polymer layer thickness)
Variable Image system PDF, optimized PDF, Optional barcode system
Supported image standards PDF,PDF/VT,TIFF, JPEG, BMP & other data base files
Substrates Offset, Digital, Plastics, Laminated and coated substrates
Printing image width 280mm (extendable to 320 mm)
Polymer WB-DS-Clear Polymer
Polymer layer thickness From 10 up to 180 microns
Ink curing Inter UV-LED Pre-curing/Full curing by UV-LED
Unwinder diameter Max. 700mm, Core 76mm
Rewinder diameter Max. 700mm, Core 76mm
Substrates thickness 30-400 micro
Substrates width 330mm
Press with Foil station dimensions (LxHxW) 3500mmx1900mmx1800mm
Operating environment Temperature: 15ºC-30ºC, Humidity: 40%-80% relative humidity
Electrical requirements Voltage: 3x380, ±5% 3 phases
+G+N Frequency: 50/60 Hz
Current: Avg. 25 Amps in Production
Weight 2800kg

Features:

Sturdy structure (double wall panel design)
Thick and thin materials, stability, mature platform
High stability
Good material applicability
No heating required
LED UV+water cooling roller
Suitable for ordinary cold foil
High quality-details, sharp edges:
Less heat, higher stability
Patented technology-better detail performance
Multi-process completed at one time
Customizable

Digital Enhancement Inkjet Digital Printer With UV Varnish And Foil Stamping 1

Digital post-press enhancement technology can realize the superposition application of a variety of post-press processes, which is not easy to achieve in the previous traditional processes, such as spot varnish, embossing, foiling and other effects, and even can realize the superposition of a variety of color foiling, so that designers have more creative imagination space and add value for products.

Washi tape is commonly made in a variety of decors, so EcooSpark is widely used in the use of adhesive paper, beautify , decoration, DIY and other purposes, such as luxury jewelry labels, wine labels, cosmetic labels, W2P and other printing companies


Features




EcooSpark enhancement printing machine mainly has the following advantages:


Cost efficiency: There is no need for plate making, the setup time is shorter, and it also has the cost advantage ofundertaking end user orders.

Higher quality: High shining surface finish, can be repeatedly stacked, with variable foiling technology, etc, which canbe comparable to the traditional post-press process in the production process, and the registration accuracy is muchhigher than that of traditional printing technology. The "raise effect" or "embossing" effect is achieved by superimposedink lavers, and different heights can be stacked at the same time on the surface of the same substrate.

Environment Friendly: ln addition to the short setup time, this is also manifested in terms of simpler operation and
VDP design.

Multi-process: High turnover rate, controllable and adjustable, reduce waste, foiling, convex foiling, spot varnishreverse varnish, Braille and other processes can be completed at one time. Using a piezoelectric inkiet head, a speciadigital UV varnish"la special formulation of transparent UV ink) is sprayed onto the substrate on demand to achieve spotvarnish, and the scope and shape of the varnishes are variable. At the same time, the highlight and matte effects can beachieved in a single printing.
Regardless of whether the previous process is offset printing, gravure printing, flexographic printing or other printingEcooSpark can fully digitally realize spot varnish, cold foiling, embossing and other digital enhancement processes, withhigh efficiency, low cost, high added value and other advantages, can help enterprises quickly complete extremelyshort to medium length orders, instantly achieve the unigue visual effect of printing. In addition, the equipment can alsocooperate with traditional printing, digital printing and other post press processes to issue encounter by other processproblems, so as to find new profit growth points for printing enterprises.

Effect of different thickness of foiling line on BOPPPPPETArt Coated paper

Digital Enhancement Inkjet Digital Printer With UV Varnish And Foil Stamping 2

Effect of different type of fonts

Digital Enhancement Inkjet Digital Printer With UV Varnish And Foil Stamping 3

Digital Enhancement Inkjet Digital Printer With UV Varnish And Foil Stamping 4





Foiling Workflow



Digital Enhancement Inkjet Digital Printer With UV Varnish And Foil Stamping 5



Our Advantage




Digital Enhancement Inkjet Digital Printer With UV Varnish And Foil Stamping 6





Producing And Packing






Digital Enhancement Inkjet Digital Printer With UV Varnish And Foil Stamping 7



Digital Enhancement Inkjet Digital Printer With UV Varnish And Foil Stamping 8



Digital Enhancement Inkjet Digital Printer With UV Varnish And Foil Stamping 9

More Details





Digital Enhancement Inkjet Digital Printer With UV Varnish And Foil Stamping 10



Digital Enhancement Inkjet Digital Printer With UV Varnish And Foil Stamping 11



FAQ



1. What are the postpress effects achieved by this machine?
Cold foil stamping, varnishing, 3D shining and embossing.

2. Can this model do color printing?
No. it you need a hybrid label printing machine which can do both printing and postpress printing, you can consider our other models. Please consult our sales.

3. How about the lead time and payment term?
We need 45 days to produce this machine. Normally our payment term is 30% deposit and 60% balance before shipment and 10% after installation.

4. How about the installation and operation training?
Our senior will fly to your location to do installation and training. It takes about 2 weeks. The service is free of charge but we will need the buyer to take the round trip freight and local hotel and meal cost.

5. Can you visit your factory?
Yes, our sales center based in Hangzhou and our factory based in shanghai. You are warmly welcome to visit us.

6. Can you do the sample as we required?
Yes, we can sample your artwork on your specified printing substrate and then courier to you. and also shoted the printing procedure for your reference.

7. Is the machine printing white?
No. This is not a color printing machine. It is more like a varnish-jet postpress machine.

8. is the machine all digital? what are the other similar machines in the markets?
Yes, all postpress procedures are digital, without any blanket or flexo plate. Just similar to Domino, HP, Epson and screen related products. But much more affordable.
