Brief Introduction:
Have you or your customers been struggling the pain points in traditional offset book and periodical pringting?
ECOO-P5600 would be your answer. More Affordable Inkjet POD Solution in the World!
• Market proved drop-on-demand industrial ink-jet head technology
• Total roll-to-sheet print-on-demand ink-jet print solution
• Short-run mono-color duplex or dual-color duplex book and periodical printing
• Flexible deployment of structure, easily expand to dual-color duplex or spot color
• Sales price competitivity as affordable as offset press
| Model | Ecoo-P5600 | Ecoo-P4400 |
| Inkjet head | Drop-on-Demand Piezoelectric, powered by Kyocera | |
| Resolution | 600dpi*600dpi/2bit, 600dpi*1,200dpi/2bit (on half speed) | |
| Max. printing speed | 100m/min | |
| Max. media width | 560mm | 440mm |
| Max. printing width | 540mm | 432mm |
| Printing mode | Monochrome duplex(Pxx12), dual-color simplex(Pxx21); Dual-color duplex(Pxx22) | |
| Media feeding mode | Roll to roll, with inline buffer, cutter and stacker | |
| Media thickness | 45 gsm - 165 gsm | |
| Media type | Offset paper, newspaper, inkjet coated paper | |
| Ink | Water based pigment ink, dye ink | |
| Dry method | Infrared dryer (automatic adjustment on printing speed) | |
| Digital front-end | Founder EagleJet™inkjet imaging system (Windows Server based) | |
| Optional | Image inspection, folding (3rd party) | |
| Operating environment | Temperature: 22.5ºC-27.5ºC, humidity:40%-80%(air conditioning recommend ) | |
| AC power | Mechanical platform: 380 VAC / 15 KW max | |
| Dryer system: 380 VAC / 1-35 KW | ||
| Controller system: 220 VAC / 6KW max | ||
| Installation space | 16,400*5800*3000mm | |
Core Technologies
• Inkjet printhead control
• Circulating ink supplying control
• Automatic printhead self-clean system
• Fast-speed paralleling RIP
• Variable data processing
• Special multiple grade-level FM screening for inkjet
Productivity
• Practical printing speed: 99 m/min
• Power-on to ready time: <20 minutes
• Daily maintenance time: <20 minutes
• Daily running time: >20 hours
• 63,000 A4 prints per hour on average speed at 85 m/min
• Average sales: lower than laser and approaching to offset
• Competitive balance: 2,000-3,000 copies comparing to offset
Key features
• 64-bit system, more memory space, higher performance, up to 1,600 A4 prints per minute
• Independent and stable tension control, to avoid the damage of printhead caused by the moving paper in unstable tension
• Optimized structure of printhead module, to simplify the services of manufacture, installation and maintenance
• Re-designed and patented paper feeding route, to get to the root of the problem of hurting the printhead module caused by high temperature air while printing back face
• Implemented QR code to monitor the correction of whole job, including JobID, Copy#, Page#, Front/Back, etc.
• Re-designed drying system, narrow spectrum, to save power consumption by 50%
• Independent and centralized ink supplying cabin (from main press), easy to deploy and extend the ink supplying ability for more press
• Untouched self-clean system, longer life of printhead
• Remote diagnosis and license management via internet
• Support multiple languages: Chinese, English, Korean
Producing And Packaging
FAQ
1. what about the payment term?
Normally, 30% deposit, 70% before shipping, or LC at sight.
2. What is the Lead Time ?
Usually 30-40 days, and we will try our best to meet your demands.
3. What about the Installation and After-sales technician support ?
Our engineers are all can go to help the installation and provide the necessary training. The buyer should take the round air tickets and service charge and the local accommodation cost. Any problems or questions, we will be at your disposal 7x24 hours.
4.Do you have any other products?
We also offer other postpress machines for package and label printing companies, like UV coating machine, laminating machine, window patching machine, carton inkjet printing machine and digital label printing machine, thermal paper slitting machine.
5. What about the Installation and after-sales technician support?
Our engineer can go to help the installation and provide the necessary training. The buyer should take the round air plane tickets and service charge
and the local accommodation cost. Any problems or questions, we will be at your disposal 7x24 hours.
