Resin Ink For Offset Printing Model: INK-D
Brief Description:
ECOO-IN-D printing ink is developed by the latest European technology system. It is made from polymeric, high-soluble resin and newly-invented paste pigment. This product is suitable for printing packaging, advertisement, label, high-quality brochures and decorative products on art paper, coated paper, offset paper, cardboard, etc., especially suitable for medium and high-speed printing.
Tecnical Data:
| ITEM/TYPE |
TACK VALUE |
FLUIDITY (mm) |
PARTICLE SIZE (μm) |
GLOSS |
SETTING TIME (min) |
DRYING TIME (hr) |
SKINNING TIME (hr) |
|
D YELLOW |
8-9 |
39±1
|
12.5 | 85 | 4 | < 8-10 | >20 |
|
D MAGENTA |
8.5-9.5 |
40±1
|
12.5 | 75 | 4 | < 8-10 | >20 |
|
D CYAN |
8.5-9.5 |
39±1
|
12.5 | 75 | 4 | < 8-10 | >20 |
|
D BLACK |
9-10 |
38±1
|
12.5 | 80 | 4 | < 8-10 | >20 |
| Tack Value | The value is measured in 1 minute by inkometer at 32℃ and 400rpm. | ||||||
| Set Time | Printing adapter, 157g art paper, the volume of ink-coating can be up to 0.125cc. | ||||||
| Condition of test | Room temperature 25℃, humidity 65%-75% | ||||||
| ITEM/TYPE |
Light Resistance |
Heat Resistance |
Acid Resistance |
Alkaline Resistance |
Alcohol Resistance |
Soap Resistance |
|
D YELLOW |
3-4 | 5 | 5 | 4 | 4 | 4 |
|
D MAGENTA |
3-4 | 5 | 5 | 5 | 4 | 5 |
|
D CYAN |
6-7 | 5 | 5 | 5 | 5 | 5 |
|
D BLACK |
6-7 | 5 | 5 | 5 | 5 | 5 |
| Light Fastness | 1-8 (weak-strong) | |||||
| Others | 1-5 (weak-strong) | |||||
Features:
Printing speed: 10000rph-13000rph
Environment friendly
Anti-skinning performance
Good water/ink balance
Rich in printing layer
Clear and complete in printing dots
Quick-drying performance, quick setting, quick turn
