Digital Binder Fully Automated Single-Clamp Perfect Binder
Digital Robot 500C is a fully automated single-clamp perfect binder with max. speed up to 360 cycles/hour. It features fully automated set-up through touch screen or via barcode scanning, integrated thickness auto-measurement, short changeover time for various binding formats, interchangeable EVA and PUR system (option). Book of one production takes on a new level of convenience and stability.
|Model||Digital Robot 500C|
|No. of Clamps||1|
|Max. Production Speed||400 books/h|
|Book Block Length (a)||120-370 mm|
|Book Block Width (b)||100-300 mm|
|Book Block Thickness (c)||1-60 mm|
|Cover Length (d)||120-370 mm|
|Cover Width (e)||220-620 mm|
|Power Required||11.5 kw|
Touch Screen Control System
The icon-based 10-inch touch screen enables ease of operation. Inputting required book format and production parameters on the touch screen or via scanning barcode, the set-up will be automatically finished in 30s at the fastest speed. The control system can memorize 99 jobs and be retrieved as requested.
Penumatic Book Clamp
Simply put the book block in the pneumatic book clamps, book thickness will be automatically measured, and all revelvant work steps are set accordingly. The vibration unit aligns the book block precisely before the book clamps close. The double activation button and safety light curtain ensure high-safety operation.
Step motor allows milling station opening width to auto adjust according to the detected thickness.
While Space-saving design integrated milling and notching, brushing. Operator can use switch handle to easily enable and disable milling as needed.
Moveable EVA Spine Gluing Station
Dual spine gluing rollers guarantee top binding quality. Spine gluing length and thickness are adjusted automatically and accurately. Changeover between EVA and PUR system can be easily completed in minutes.
Independent Side Gluing Station
Opening width of two side gluing rollers is automatically adjusted by step motor. Even and thin side glue is applied by the independent side gluing station with two application discs.
Cover Feeding Station
Top in-feed cover feeder design significantly reduce drag marks. Cover scoring position is automatically adjusted according to the input thickness; Sensitive double-feed and miss-feed defection device ensure accurate feeding for every cover.
Pneumatic Nipping Station
The pneumatic controlled nipping station can be automatically adjusted at the fastest speed according to the book block thickness. Thanks to the accurate and reliable nipping mechanism, cover can be precisely and firmly nipped with the book block.
Producing and Packaging
From producing to delivery, we make every details very carefully to guarantee the good product quality and service to customers.
