760*560mm Rigid Paper Box Making Machine Automatic Setting

1 SET
MOQ
Negotiable
Price
760*560mm Rigid Paper Box Making Machine Automatic Setting
Features Gallery Product Description Request A Quote
Features
Specifications
Classification: Paper Box Making Machine
Paper Thickness: 80-350 G/Sqm
Working Speed: 15-25 PCS/Min
Cardboard Thickness: 0.8-3mm
Max Cardboard Size: L760 * W560mm
Min. Cardboard Size: L120 * W100mm
Edge Folding Size: 10-90mm
Tuin In Depth: 15-80mm
Air Pressure: 40L/min 0.8MPa
High Light:

760*560mm Paper Box Making Machine

,

3mm Cardboard Box Making Machine

,

PLC Cardboard Box Making Machine

Basic Infomation
Place of Origin: China
Brand Name: EcooGraphix
Certification: ISO9000, CE
Model Number: ECOO-LS1246B
Payment & Shipping Terms
Packaging Details: Standard Export Packing
Delivery Time: 45 Days
Payment Terms: L/C, T/T
Supply Ability: 500 Sets/Year
Product Description



 760*560mm Max. Cardboard Size Gift Rigid Box Former








-- -- -- = = = ≡ ≡ ≡ = = = -- -- --  Features  -- -- -- = = = ≡ ≡ ≡ = = = -- -- --


  1. Automatic setting function
  2. Storage function for the positioning part, easy to adjustment
  3. Pick up box system, can avoid scraping on cover paper, suitable for high end boxes
  4. Import durable part, like Mitsubishi servo motor, YAMAHA robotic arm, Panasonic PLC, Double Germany cameras (1000 Pixels)
  5. Special pick up and wrapping system
  6. Anti-leaking gluing system
  7. Servo motor feeding system
  8. Single forming part
  9. Quick job setting, no need to change air pressing plate; No need to change tuck in blade; No need to move camera for size changing, quick job changing
  10. Can make big size box, such as 600*400mm, and the height can reach 120mm
  11. Memory function for size setting





-- -- -- = = = ≡ ≡ ≡ = = = -- -- --  Specification  -- -- -- = = = ≡ ≡ ≡ = = = -- -- --



Heaven And Earth Box Forming Machine

Model
ECOO-LS1246B

Max. Paper size
L800 * W600mm

Min. Paper size
L135 * W100mm

Max. cardboard size
L760 * W560mm

Min. cardboard size
L120 * W100mm

Max. box size
L600 * W400 * H120mm

Min. box size
L80 * W65 * H15mm

Paper thickness
80-350g/m2

Cardboard thickness
0.8-3mm


Edge folding size
10-90mm

Tuin in depth
15-80mm

Air pressure
40L/min, 0.8MPa

Working speed
15-25 pcs/min

Motor power
14kw/380v, 3 phase

Heating power
8kw/380v, 3 phase

Machine weight
3800kg

Machine dimension
L6600 * W3800 * H3000mm

Heaven And Earth Box Forming Machine
Model ECOO-LS1246B
Max. Paper size L800 * W600mm
Min. Paper size L135 * W100mm
Max. cardboard size L760 * W560mm
Min. cardboard size L120 * W100mm
Max. box size L600 * W400 * H120mm
Min. box size L80 * W65 * H15mm
Paper thickness 80-350 g/m2
Cardboard thickness 0.8-3mm
Edge folding size 10-90mm
Tuin in depth 15-80mm
Air pressure 40L/min, 0.8MPa
Working speed 15-25 pcs/min
Motor power 14kw/380v, 3 phase
Heating power 8kw/380v, 3 phase
Machine weight 3800kg
Machine dimension L6600 * W3800 * H3000mm









-- -- -- = = = ≡ ≡ ≡ = = = -- -- --  Work Flow  -- -- -- = = = ≡ ≡ ≡ = = = -- -- --



760*560mm Rigid Paper Box Making Machine Automatic Setting 0





-- -- -- = = = ≡ ≡ ≡ = = = -- -- --  Details  -- -- -- = = = ≡ ≡ ≡ = = = -- -- --

760*560mm Rigid Paper Box Making Machine Automatic Setting 1
760*560mm Rigid Paper Box Making Machine Automatic Setting 2




-- -- -- = = = ≡ ≡ ≡ = = = -- -- --  Producing And Packaging  -- -- -- = = = ≡ ≡ ≡ = = = -- -- --

From producing to delivery, we make every details very carefully to guarantee the good product quality and service to customers.


760*560mm Rigid Paper Box Making Machine Automatic Setting 3

760*560mm Rigid Paper Box Making Machine Automatic Setting 4



760*560mm Rigid Paper Box Making Machine Automatic Setting 5



760*560mm Rigid Paper Box Making Machine Automatic Setting 6



760*560mm Rigid Paper Box Making Machine Automatic Setting 7



760*560mm Rigid Paper Box Making Machine Automatic Setting 8



760*560mm Rigid Paper Box Making Machine Automatic Setting 9





-- -- -- = = = ≡ ≡ ≡ = = = -- -- --  Certifications  -- -- -- = = = ≡ ≡ ≡ = = = -- -- --

760*560mm Rigid Paper Box Making Machine Automatic Setting 10

760*560mm Rigid Paper Box Making Machine Automatic Setting 11




-- -- -- = = = ≡ ≡ ≡ = = = -- -- --  FAQ  -- -- -- = = = ≡ ≡ ≡ = = = -- -- --




 Q1: What are your main products ?


A: Our main products are the Prepress 4up and 8up Online/Offline Thermal CTP, CTCP, VLF CTP, Flexo CTP, Processor, Offset Plates, Offset Inks, Offset Printing Blankets, Postpress Packing Equipment and so on.


You can get the equipment and consumables all in one and no worry about the after-sales service from our company.





 Q2: Where is your factory ?


A: Our CTP Processor machine factory is in Shanghai, you are warmly welcome to visit our factory!





 Q3: What is your warranty for the CTPs ?


A: Three years' Laser Head and main spare parts for the CTPs, one year for the Processor.


If the customer uses EcooGraphix CTP plate with the CTP machine, we will provide the Lifetime Warranty.





 Q4: Can you also supply the Workflow and RIP ?


A: Yes, we can provide the Workflow Brainnew and RIP Compose V12.





 Q5: What about the installation and after-sales technician support ?


A: Our engineer can go to help the installation and provide the necessary training. The buyer should take the round air plane tickets, service charge and the local accommodation cost. Any problems or questions, we will be at your disposal 7x24 hours. Among our large amount of CTP installations worldwide, there are also many end users(printers) who have purchased the CTP products from EcooGraphix China directly and EcooGraphix technical service team support these installations remotely with regular onsite visits.



These end users printers all run the CTP systems with full satisfaction due to our robust quality, seamless remote service, thorough training and maintanence. If you are a printer who is considering purchasing directly from EcooGraphix China, there is no hassle on installations, training and after sales service. We guarantee your satisfaction.






Video ☞ https://youtu.be/MlRZKzCuNQ8
