Multi Color Fully Automatic Label Printer Machine 330mm Width

1 SET
MOQ
Negotiable
Price
Multi Color Fully Automatic Label Printer Machine 330mm Width
Features Gallery Product Description Request A Quote
Features
Specifications
Machine Type: Label Printing Machine
Color: Cmyk + White/ Orange/ Purple/ Green
Printing Speed: 50m/min - 75m/min
Resolution: 600*600dpi, 600*1200dpi Native, 4 Level Gray Scale
Printing Technology: UV-Piezo Dod-Inkjet
Printing Width Available: 216/ 324mm
Ink Curing: Inter UV-LED Pre-Curing And Full Curing By UV-LED
Substrates: 20-400 Micro(Label Paper Supported)
High Light:

UV Piezo Label Printer Machine

,

330mm Width Label Printer Machine

,

75m/Min Label Printer Machine

Basic Infomation
Place of Origin: China
Brand Name: EcooGraphix
Certification: ISO9000, CE
Model Number: RG PLUS
Payment & Shipping Terms
Packaging Details: Standard Export Packing
Delivery Time: 45 Days
Payment Terms: L/C, T/T
Supply Ability: 500 Sets/Year
Product Description



 Multi Colors Fully Automatic Digital Label Printer Machine












--¯¯¯-  Innovation & Manufacturing  --¯¯¯-




The label printing market is going through a transaction period where run lengths are becoming shorter and shorter, media costs are increasing, margins are shrinking and fast turnaround time to market is creating huge pressure on label printers.


Here EcooGraphix & Winbosc bridges the gap between the end users, the brand owners and the label printers enabling them to print on demand. EcooGraphix & Winbosc Printing Press tilizes the PiezoDOD inkjet print head technology that enables it to print high quality labels at 600*600 DPI native resolution at speeds up to 70m/min and up to 330 mm of print widths, delivering the expectations of a label printer in terms of lowest total cost of ownership and fastest return on investments.

Digital is the future, so is the Digital press, it comes with the power of printing short to medium runs very effectively and economically, additionally featuring great value of personalization, variable data and security printing in real time production at one go.







--¯¯¯-  Specification  --¯¯¯-





ECOO RG PLUS Digital Label Printer Machine

Model

RG PLUS

Max. Width
330mm


Printing speed
50m/min - 75m/min

Substrates
20-400 micro(Label paper supported, other materials need test)


Color
CMYK + White/ Orange/ Purple/ Green

Printing Width Available
216/ 324mm


File format
PDF, PDF/VT, TIFF, JPEG, BMP & other data base files

Printing Technology
UV-Piezo DoD-inkjet


Resolution
600*600dpi, 600*1200dpi Native, 4 level gray scale

Ink curing
Inter UV-LED Pre-curing and Full curing by UV-LED


Unwinder diameter
Max. 700mm, Core 76mm

Rewinder diameter
Max. 700mm, Core 76mm


Other accessories
Flexo Stations, Cold Foil, Lamination, Die cut with matrix rewind&back scoring,

slitting assembly, web cleaner with antistatic, corona treater and web guide

Dimension
4200 x 1900 x 1800mm


Weight
About 3500kg

Operating environment
Temperature: 20ºC-25ºC, Humidity: 50%-70% relative humidity

ECOO RG PLUS Digital Label Printer Machine
Model RG PLUS
Max. Width 330mm
Printing speed 50m/min - 75m/min
Substrates 20-400 micro(Label paper supported, other materials need test)
Color CMYK + White/ Orange/ Purple/ Green
Printing Width Available 216/ 324mm
File format PDF, PDF/VT, TIFF, JPEG, BMP & other data base files
Printing Technology UV-Piezo DoD-inkjet
Resolution 600*600dpi, 600*1200dpi Native, 4 level gray scale
Ink curing Inter UV-LED Pre-curing and Full curing by UV-LED
Unwinder diameter Max. 700mm, Core 76mm
Rewinder diameter Max. 700mm, Core 76mm
Other accessories Flexo Stations, Cold Foil, Lamination, Die cut with matrix rewind&back scoring, slitting assembly, web cleaner with antistatic, corona treater and web guide
Dimension 4200 x 1900 x 1800mm
Weight About 3500kg
Operating environment Temperature: 20ºC-25ºC, Humidity: 50%-70% relative humidity









--¯¯¯-   Features  --¯¯¯-




♠  7-color digital printing, covering 95% of Pantone colors

♦  New upgraded design, simple operation

♣  Fully automatic integrated program to improve efficiency

♥  Built-in quality inspection device, real-time color inspection and quality control

♠  Support remote operation and maintenance

♦  Upgrade printing control software to optimize production process







--¯¯¯-  Application & Technology  --¯¯¯-




RG PLUS can print most of label materials, such as Paper, Kraft, Wine Label, PET, PP, Washi Tape, Metalized Material, Aluminum Foil…



Multi Color Fully Automatic Label Printer Machine 330mm Width 0



Multi Color Fully Automatic Label Printer Machine 330mm Width 1



Multi Color Fully Automatic Label Printer Machine 330mm Width 2









--¯¯¯-  Producing And Packaging  --¯¯¯-




From producing to delivery, we make every details very carefully to guarantee the good product quality and service to customers.



Multi Color Fully Automatic Label Printer Machine 330mm Width 3Multi Color Fully Automatic Label Printer Machine 330mm Width 4



Multi Color Fully Automatic Label Printer Machine 330mm Width 5



Multi Color Fully Automatic Label Printer Machine 330mm Width 6



Multi Color Fully Automatic Label Printer Machine 330mm Width 7









--¯¯¯-  Certifications  --¯¯¯-




Multi Color Fully Automatic Label Printer Machine 330mm Width 8



Multi Color Fully Automatic Label Printer Machine 330mm Width 9









--¯¯¯-  FA --¯¯¯-




Q1: What are your main products ?


A: Our main products are the Prepress 4up and 8up Online/Offline Thermal CTP, CTCP, VLF CTP, Flexo CTP, Processor, Offset Plates, Offset Inks, Offset Printing Blankets, Postpress Packing Equipment and so on.


You can get the equipment and consumables all in one and no worry about the after-sales service from our company.







Q2: Where is your factory ?


A: Our CTP Processor machine factory is in Shanghai, you are warmly welcome to visit our factory!







Q3: How long is the lead time ?


A: The lead time is normally 30 days. We can accelerate for emergency cases.







Q4: Is there any certification for your machine ?


A: Yes, all our machines have been certified by SGS and CE.







Q5: How long is the warranty period ?


A: EcooGraphix guarantees 1 year of warranty for laser head and spare parts.







Q6: What is your normal payment term ?


A: Normally, 30% TT deposit, 70% before shipping, or LC at sight.







Q7: What about the installation and after-sales technician support ?


A: Our engineer can go to help the installation and provide the necessary training. The buyer should take the round air plane tickets, service charge and the local accommodation cost. Any problems or questions, we will be at your disposal 7x24 hours. Among our large amount of CTP installations worldwide, there are also many end users(printers) who have purchased the CTP products from EcooGraphix China directly and EcooGraphix technical service team support these installations remotely with regular onsite visits.



These end users printers all run the CTP systems with full satisfaction due to our robust quality, seamless remote service, thorough training and maintanence. If you are a printer who is considering purchasing directly from EcooGraphix China, there is no hassle on installations, training and after sales service. We guarantee your satisfaction.
