Large Size Offset Printing Plate Making CTP Machine
❤ Application
EcooGraphix Thermal CTP(Computer To Plate) Plate Making Machine is the first Prepress necessity of quick short-run offset printing. It can output the images on the computer to printing CTP plate directly through the CTP machine and save the film and labor.
By the EcooGraphix CTP, the customer can get excellent output image quality, highly reliable stability, less space occupied with more flexibility.
ღ Specification
ECOO VLF (Very Large Format) T-1600S CTP Specifications
Model
T-1600S
Exposing Method
External Drum
Imaging System
64-channel, Discrete 830nm laser diode
Output Speed
16plates/hour, 1470mm x 1180mm/ 2400dpi
Plate Sizes
Max. 1470mm x 1180mm; Min. 300mm x 400mm
Exposing Size
Max. 1470mm x 1164mm
Media Type
Thermal CTP plate
Plate Thickness
0.15mm to 0.30mm or 0.25mm to 0.40mm(alternative)
Resolution
2400dpi
Repeatability
±5μm(Continuous exposing for 4 times or above on the same plate with
a temperature of 23ºC and humidity of 60%)
Interface
USB 2.0 or USB3.0(USB2.0 is recommended)
Plate Loading
Semi automatic
Net Weight
1400kg
Machine Size(WxLxH)mm
2355 x 1910 x 1217
Power Supply
Single phase: 220V-240V, Power Consumption(peak value): 5.5KW
Environment
Recommended: 21-25ºC; Max. 15-30ºC, Humidity: 40%-70%RH
| ECOO VLF (Very Large Format) T-1600S CTP Specifications | |
| Model | T-1600S |
| Exposing Method | External Drum |
| Imaging System | 64-channel |
| Discrete 830nm laser diode | |
Output Speed |
16plates/hour |
| 1470mm x 1180mm/ 2400dpi | |
| Plate Sizes | Max. 1470mm x 1180mm; Min. 300mm x 400mm |
| Exposing Size | Max. 1470mm x 1164mm |
| Media Type | Thermal CTP plate |
| Plate Thickness | 0.15mm to 0.30mm or 0.25mm to 0.40mm(alternative) |
| Resolution | 2400dpi |
| Repeatability |
±5μm(Continuous exposing for 4 times or above on the same plate with a temperature of 23ºC and humidity of 60%) |
| Interface | USB 2.0 or USB3.0(USB2.0 is recommended) |
| Plate Loading | Semi automatic |
| Net Weight | 1400kg |
| Machine Size(WxLxH)mm | 2355 x 1910 x 1217 |
| Power Supply | Single phase: 220V-240V, Power Consumption(peak value): 5.5KW |
| Environment | Recommended: 21-25ºC; Max. 15-30ºC, Humidity: 40%-70%RH |
❦ Details
❧ Producing And Packaging
From producing to delivery, we make every details very carefully to guarantee the good product quality and service to customers.
❤ Certificates
ღ FAQ
Our engineer can go to help the installation and provide the necessary training. The buyer should take the round air plane tickets, service charge and the local accommodation cost. Any problems or questions, we will be at your disposal 7x24 hours. Among our large amount of CTP installations worldwide, there are also many end users(printers) who have purchased the CTP products from EcooGraphix China directly and EcooGraphix technical service team support these installations remotely with regular on site visits.
These end users printers all run the CTP systems with full satisfaction due to our robust quality, seamless remote service, thorough training and maintenance. If you are a printer who is considering purchasing directly from EcooGraphix China, there is no hassle on installations, training and after sales service. We guarantee your satisfaction.
