Digital Paper Package Box Window Box Patching Machine

Digital Paper Package Box Window Box Patching Machine
Features Gallery Product Description Request A Quote
 Max.Paper Size: (L)600×(W)520
Max.Window Size: (L)400×(W)400
 Machine Size: (L)4500×(W)1500×(H)1700
Film Thickness: 0.03-0.2µm
Paper Thickness: Cardboard: 200gr/m2~2.000gr/m2 Corrugated Board: From Micro-flute~6mm Thickness
Stickup Accuracy: Left/right)±0.5mm ;(top/bottom)±1mm
High Light:

digital window patching machine


paper package box window patcher

Basic Infomation
Place of Origin: CHINA
Certification: CE
Model Number: RT600
Payment & Shipping Terms
Packaging Details: Standard Export Packing
Delivery Time: 30DAYS
Payment Terms: L/C, T/T
Product Description

Automatic Digital Cutter Paper Package Box Window Patching Machine

Technical Specifications:

Model/Specification RT-600 Automatic Window Patching Machine
Max.Paper size (L)600×(W)520
Min.Paper size (W)80×(L)100mm
Max.Window size (L)400×(W)400
Min.Window size (W)30×(L)45mm
Paper thickness cardboard: 200gr/m2~2.000gr/m2
corrugated board: from micro-flute~6mm thickness
Film thickness 0.03-0.2µm
Stickup Accuracy (left/right)±0.5mm ;(top/bottom)±1mm
Machine size (L)4500×(W)1500×(H)1700
Net weight 3300kg
Main power required 3kw
Sizing roller power 0.09kw
Delivery stacker power 0.37kw


Digital Paper Package Box Window Box Patching Machine 0

Film material:
Applicable to PET, PVC, PP, OPP, PE, Asha and even paper.
It can also be used for films with special effects such as light film, dumb film, flash film, colored film, printed film, UV filter film and fluorescent film.

Digital Paper Package Box Window Box Patching Machine 1


1. Sizing Part(gluing):
The Gluing Section consists of the chrome-plated glue roller, glue separation plate, side guide and glue mould roller.
The Gluing Section can be easily pulled out ,it's easy to set and clean.
The glue separation plate is adjustable to control the glue area and amount.
In case of the machine shutdown, the cylinder will lift the glue roller and then the machine will be driven by the other separate motor ,to avoid the leaking of the glue.
Option of pre-make ready table is available, Operator can set up the mould outside of the machine. It's convenient and time saving.
Digital Paper Package Box Window Box Patching Machine 2


2. Paper collecting part (delivery stacker)
The belt at the Delivery Section is wide. Operator can adjust the height of the belt and the finished products are aligned in a straight line.
Belt speed can also be adjusted to be synchronized with the machine speed.

Digital Paper Package Box Window Box Patching Machine 3


3. Feeder part (paper feeding)
The machine is equipped with lower belt feeding system, with the choice of option which is pilling lifting system and belt lifting system.
The characteristic of the belt lifting system is high speed thus increasing capacity.
The characteristic of the pilling lifting system is that the feeding belt can be run continuously while boxes can go through the upward/downward movable pilling lifting system. This pilling lifting system is flexible in capable of feeding different boxes without scratching the boxes.
The feeding system design is an advance technology. Synchronous belt feeder is equipped with suction system. At the chain adjusting section there are four feeding chains.
There is a feeding gate at the feeder which allows you to adjust upper rail without additional tool. This upper rail is made of flat steel and is connected to the middle part of the frame.
This system is reliable which ensure the registration of all, cardboard and chain is accurate.
Even when there is serious jam, the position is precise and you can use micro-adjustment to adjust.
Digital Paper Package Box Window Box Patching Machine 4Digital Paper Package Box Window Box Patching Machine 5



4. Window patching part
Boxes are delivered from the gluing section to the window patching section by suction.
Suction is run individually and registered by sensor. When there is blank sheet, the suction table will go down to avoid sticking of glue on the belt.
Operator can adjust the volume of suction air according to the size of the box.
The suction cylinder is made of special material. It is smooth so that the speed of patching is high and there will be no scratch on the plastic film.
When the knife cylinder is rolling, it intercrosses with another fixed knife bar and hence cutting the plastic film like "scissors". The cutting edge is flat and smooth.
The knife cylinder is with adjustable blowing or suction system to ensure the plastic film is patched on the window of the box accurately.

Digital Paper Package Box Window Box Patching Machine 6
