Brief description
CB03II series is our classic digital cutting series, which include 4 format. This series is designed for package industry and advertising industry. The CB03II-1113 is the smallest format within this series, using for label printing and some small format packaging printing. The max. cutting size is 1100*1300mm. We have optional flatbed optional for other 3 format, fixed flatbed and conveyor flatbed design, but this size has only fixed flatbed. So some banner cutting or plastic film cutting will not be suitalbe. Hope you like it.
Application
All kinds of corrugated paperboard, grey board, KT board, PVC expansion sheet, honey comb board, car sticker, light slide, PP gum, flex banner, flag fabric, EPE foams, EVA, PVC plate, acrylic, thick foam, etc
Technical data
| Model | CB03II-1113 | |
| Multiple function machine head | Easy to change different tools. Engraving and routers. Oscillating through cutting/kiss cutting/ceasing/plotting/laser positioning, and precise camera registration. | |
| Tools | Various kinds of cutting blades, different size of creasing wheels. | |
| Safety device | Infrared sensor, responsive, safe and reliable | |
| Moving speed | Up to 1500mm/s | |
| Cutting speed | Up to 1200mm/s(depend on the kinds of material) | |
| Cutting thickness | ≤50mm(customized according to different materials) | |
| Cutting material | All kinds of corrugated paperboard, grey board, KT board, PVC expansion sheet, honey comb board, car sticker, light slide, PP gum, flex banner, flag fabric, EPE foams, EVA, PVC plate, acrylic, thick foam, etc | |
| Cutting material affixed | Smart (optional) individual multi-zone vacuum suction | |
| Repeatability | ±0.05mm | |
| Interface | Ethernet port | |
| Numerical control panel | Multi-language LCD Touch Scream | |
| Transmission | Imported (digital servo motors, straight rail, synchronous belt, guide screw) | |
| Related powder | 7.5 kw | |
| Related voltage | 380V/220V±10%, 50hz/60hz | |
| Max. cutting size | 1100mmx1300mm | |
| Machine size | 2250mmx2320mmx1280mm | |
Cutting blade or cutting head
