T1600 VLF CTP Machine For Packaging Carton Sheetfed Printing
EcooSetter VLF T-1600MX UV- CTP
Characteristic
Maximum size of plate: 1,680×1350mm
Features: Super Fast Output speed up to 27PPH ,Less manpower, high stability and perfect output quality.
Automatic Plate loading and unloading improves your plate-making efficiency.
Equipped with 256CH screen square dot imaging technology, its ultra-large format model is one of the fastest fully automatic platesetters on the market, combining fast, automated, and high-quality imaging features
Other similar models
| EcooGraphix VLF(Very Large Format) CTP Series Specifications | ||||||
| Model | UV-1600S | UV-1600SX | T-1600S | UV-1600M | UV-1600MX | T-1600M |
| Exposing Mothod | External Drum | |||||
| Imaging System | 64-channel | 128-channel | 64-channel | 64-channel | 128-channel | 64-channel |
| Discrete 400-410nm laser diode |
Discrete 400-410nm laser diode |
Discrete 830nm laser diode |
Discrete 400-410nm laser diode |
Discrete 400-410nm laser diode |
Discrete 830nm laser diode |
|
| Output Speed | 16plates/hour | 27plates/hour | 16plates/hour | 10plates/hour | 18plates/hour | 10plates/hour |
| 1470mm x1180mm /2400dpi | 1630mm x 1325mm / 2400dpi | |||||
| Plate Sizes | Max.1470mm x1180mm; Min. 650mm x 550mm |
Max.1680mm x1350mm; Min. 650mm x 550mm |
||||
| Exposing Size | Max. 1454mm x 1164mm | Max. 1680mm x 1336mm | ||||
| Media Type | positive UV-CTP plate | positive thermal CTP plate | positive UV-CTP plate | positive thermal CTP plate | positive UV-CTP plate | positive thermal CTP plate |
| Plate Thickness | 0.15mm to 0.30mm or 0.27mm to 0.40mm(alternative) | |||||
| Resolution | 2400dpi | |||||
| Repeatablity | ±5μm(continuous exposing for 4times or above on the same plate with a temperature of 23ºC and humidity of 60%) | |||||
| Interface | USB 2.0 or USB3.0(USB2.0 is recommended) | |||||
| Plate Loading | semi automatic(alternative autoloader system) | |||||
| Net Weight | 2600kg | 1800kg | ||||
| Machine Size (WxLxH)mm |
2355x1910x1217 | 2400x1430x1110 | ||||
| Power Supply | single phase:220V-240V, power Consumption(peak value):5.5KW | |||||
|
recommended temprature:21-25ºC;allowed temperature :15-30ºC, humidity:<70%RH
|
||||||
Major Highlights of EcooGraphixT-800 thermal CTP
1) Superior dot quality reproduction proven by worldwide market:
1%-99% dot reproduction
Up to 250lpi screening ,2400 dpi or 1200dpi optional
2) Fully qualified: for any thermal non-process plate and process plates.
3) Worldwide top class components and parts supplied by international well known suppliers from Japan, USA, and Germany.
4) Long warranty of the machine: 3 years warranty (free replacement of all parts)
Low Cost of Parts: after 3 year warranty, very low cost of parts. for example, laser diode at US$250 per piece.
5) Guaranteed Service: installation and training conducted by technical engineer from factory, ensuring best setup and training to be achieved.
Regular remote maintenance to be conducted every 2 month. Proactively revisit by engineers to be conducted. 7x24 hours service response.
5. Producing and Packing
From producing to delivery,we make every details very carefully to guarantee the good product quality and service to customers .
Our Partners
FAQ:
Q:What is the production time ?
A: Usually 20days, a little longer for customized model.
Q: What is the warranty time for the machine?
A: 3years’warranty for CTP machine. If customer use EcooGraphix CTP plate, all the CTP parts will be guaranteed for lifetime with no service charge.
Q:What is the payment term?
A:Normally 30% deposit,70% before shipment by T/T or LC. Other terms are negotiable.
Q:What supporting device should we prepare before installation?
A: Truck fork should be 1.5Ton or above capacity, 1.2m or longer arm;
single phase power supply,UPS,2units power supply,air compressor and so on.
Q:What about the Installation and after-sales technician support?
A:Our engineer can go to help the installation and provide the necessary training. The buyer
should take the round air plane tickets and service charge and the local accommodation cost.
Any problems or questions,we will be at your disposal 7x24 hours.
