Home /Products/Printing Consumables/Agfa Hns HS Graphi Arts Imagesetting Film For Offset Printing

Agfa Hns HS Graphi Arts Imagesetting Film For Offset Printing

200SQM
MOQ
Negotiable
Price
Agfa Hns HS Graphi Arts Imagesetting Film For Offset Printing
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Graphi Arts Imagesetting Film
Plate Type: Alliance Far Red Film
Spectral Sensitivity: Hene Laser And Red Laser Diode (630-670nm)
Description: Emulsion Coated On A 0.10 Mm Antistatic Polyester
Developer: Agfa Developers
Processing Time: 20-40 Sec
Safe Light: Dark Green, Recommended: Encapsulite T20/ND.75
Highlight:

Agfa Imagesetting Film

,

Offset Printing Imagesetting Film

,

Imagesetting Film For Offset Printing
Basic Infomation
Place of Origin: China
Brand Name: EcooGraphix
Certification: CE
Model Number: ECOO-TDS
Payment & Shipping Terms
Packaging Details: Carton Box
Delivery Time: 10-20 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 200, 000 Square Meter/Year
Product Description

Agfa Graphic Art Imagesetter Film For Offset Printing



Recording films has been the standard in the printing business for years, and your company can continue to use them. We offer original Agfa films produced in Belgium, which are then recut and repackaged at the Shanghai Agfa branch.


Our films feature an open system, high-speed, red-sensitive technology with hard dot image quality. They are designed for exposure in image setters equipped with HeNe lasers (630nm-670nm) or red laser diodes, ensuring perfect processing with compatible chemistries.



Specification

Model ECOO-HNS
Plate Type Alliance far red film
Spectral Sensitivity HeNe laser and red laser diode (630-670nm)
Description Emulsion coated on a 0.10 mm antistatic polyester base
Practical Photographic Properties with Different Engine
Engine Accuset Avantra
Int. Setting 170 230
Practical Density D.4.00-4.20 D.4.10-4.30
5% 5% 5%
50% 57% 53%
95% 98% 96%
Developer Agfa developers
Processing time 20-40 sec
Processing temperature 35ºC or 95ºF
Developer Replenishment
(eg, ACD/ASD)		 15% exposure 50ml/m²
50% exposure 150ml/m²
85% exposure 250ml/m²
Anti-OX replenishment 1000 ml/24h=0.264 US gallons/24h
Fixer Agfa fixer
Fixing temperature 32ºC or 90ºF
Fixer replenishment
(Without Fixer electrolysis)		 15% exposure 500 ml/m²
50% exposure 300ml/m²
85% exposure 100ml/m²
Fixer replenishment
with Fixer electrolysis		 125 ml/m²
Practical set-up density D 4.00-D.4.20
(dot gain depending on the optical quality of the imagesetter)
Chemical Compatibility Processable in all rapid access chemistries and in main hard dot chemistries such as RA2000, Fuji HQ QRD-1, AND QRD-1P
Dimensional Stability Humidity coef: 0.10mm base, Crh 0.016mm/m/%RH
Temp. coef: 0.10mm base, Cot 0.018mm/m/1ºC
Safe light Dark Green recommended: Encapsulite T20/ND.75 or equivalent
Storage The films are preferably stored in a cool dry place temperature below 20ºC and relative humidity between 30% and 60%



Features:
Excellent image quality: very good sharpness and high practical density
Very wide System latitude: Wide processing & exposure latitude
Very good Day to day consistency Very good batch-to-batch consistency
Convenience and ease of use because of available ECO equipment
Ecological & Economical replenishment, very Low chemistry consumption.
Linear output for conventional screening Approved for stochastic screening
Anti-static before and after processing
Open system: perfect processing in compatible chemistries

Sizes:
390mmX60m 610mmX60m
406mmX60m 660mmX60m
457mmX60m 813mmX60m
508mmX60m 838mmX60m
558mmX60m 914mmX60m
Other sizes are also available as required.



Unpacking:



Daylight Loading: The film for daylight loading can be loaded into the special cassette of the laser image output machine under normal daylight conditions.

Darkroom Loading: The film for darkroom loading should be loaded into the special cassette of the laser image output machine under a special dark green light or in complete darkness.

Handling Precautions: Handle the film with care to prevent damage from friction, folding, oil, and fingerprints.

Storage:

Store the films in a cool, dry place with a temperature not exceeding 20°C and a relative humidity (RH) below 65%. Excessive warmth and humidity can shorten the film's shelf life. Keep the films away from radiation, corrosive substances, and direct sunlight.
