Positive UV - CTP Thermal plate Developer Offset Printing Chemistry
Each CTP plate supplier provides standardized development data based on rigorous testing. While slight fluctuations in plate energy may occur during production, these are typically minor and easily addressed through fine-tuning of the developing machine. In normal circumstances, we begin by inputting the supplier's standard data into the developing machine's control system. Then, we initiate the machine with a few waste plates to stabilize its temperature, adjusting it according to the general development conditions until the desired results are achieved.
Moreover, strict attention is paid to the developer's requirements throughout the development process.
Developing CTP plates represents the most critical aspect of CTP plate production, and much of our focus centers on this stage. Many plate suppliers provide developers tailored to their plates, as the precision of CTP technology in dot reproduction demands strict adherence to chemical composition and development temperature specifications. Typically, we monitor the temperature of both the developer and the development tank before commencing development. The temperature variance among the four corners must not exceed 0.3°C, ensuring consistent and reliable results.
CTP Developer(ECOO-T) | |
Application | Development of Thermal CTP Plate |
Specialty |
Stable Performance and rapid development |
Good Protection to both image and non-image area |
|
Less harmful to the photosensitive layer and oxide layer |
|
Fast Processing speed with sharp dots and a clean background |
|
Replenishment |
120ml/SQM |
Static |
60ml/h |
Packing |
20L/drum |
Product: DEVELOPER COMPONENT (Sodium Gluconate Solution)
Hazardous Ingredients / Identity Information
Component Sodium gluconate 10% , CAS No.: 527-07-1
Others Active Solvent 3% , CAS No.: 28519-02-0
Water 87%, CAS No.: 7732-18-5
Physical / Chemical Characteristics
Boiling Point: N/A
Vapor Pressure: N/A
Vapor Density: N/A
4.0 Solubility in Water: Solubility in Water 100%
Appearance and Odor: Light Yellow Liquid, slight odor
Specific Gravity: 1.06g/cc
5.0 Melting Point: 206 °C (dec.)(lit.)
Evaporation Rate: N/A
Flash Point: N/A
Extinguishing Media: Water and sand, Foam, Dry Chemical, CO2
Unusual Hazards: Avoid liquid accumulations and sources of ignition.
FAQ:
1. What are your main products?
EcooGraphix is a leading supplier of prepress solutions, printing materials, and post-packing equipment. Our main products include Prepress 4up and 8up Online/Offline Thermal CTP, CTCP, VLF CTP and CTCP, Flexo CTP, processors, offset plates, inks, blankets, post-press packing equipment, and more. Our partners in the USA, Canada, Mexico, Colombia, Turkey, Hungary, South Africa, and other countries are highly satisfied with our technician support service and product performance. We also offer thermal CTP plates (single and double layers), positive CTCP plates (single and double layers), and chemistry-free CTP plates. With EcooGraphix, you can obtain all your prepress equipment and consumables in one place, without worrying about after-sales service.
2. Where is your factory?
Our CTP machine factory is located in Hangzhou city, approximately 1.5 hours by train from Shanghai. You are warmly welcomed to visit our factory!
3. What is your warranty for the CTPs?
We offer a three-year warranty for the laser head and main spare parts of the CTPs and one year for the processor. If the customer uses EcooGraphix CTP plates with the CTP machine, we provide a lifetime warranty.
4. What is the Lead Time?
Typically, the lead time is 10-30 days, and we will strive to meet your specific requirements.
5. Can you also supply the Workflow and RIP?
Yes, we can provide the Workflow Brain New and RIP Compose V12.
6. What about the Installation and after-sales technician support?
Our engineers can assist with installation and provide the necessary training. The buyer is responsible for covering the cost of round-trip airfare, service charges, and local accommodation. For any problems or questions, we offer 24/7 support.
