Name: Agfa Hns HS Graphi Arts Imagesetting Film For Offset Printing
Brand: Hangzhou Ecoographix Digital Technology Co., Ltd.
SKU: ECOO-TDS
Price: 50.00 USD
Availability: InStock

Features Gallery Product Description Request A Quote

Features

Specifications

Product Name: Graphi Arts Imagesetting Film

Plate Type: Alliance Far Red Film

Spectral Sensitivity: Hene Laser And Red Laser Diode (630-670nm)

Description: Emulsion Coated On A 0.10 Mm Antistatic Polyester

Developer: Agfa Developers

Processing Time: 20-40 Sec

Safe Light: Dark Green, Recommended: Encapsulite T20/ND.75

Highlight:

Offset Printing Graphi Arts Imagesetting Film

HS Graphi Arts Imagesetting Film

Basic Infomation

Place of Origin: China

Brand Name: EcooGraphix

Certification: CE

Model Number: ECOO-TDS

Payment & Shipping Terms

Packaging Details: Carton Box

Delivery Time: 10-20 days

Payment Terms: L/C, T/T, Western Union

Supply Ability: 200, 000 Square Meter/Year

Gallery

Agfa Hns HS Graphi Arts Imagesetting Film For Offset Printing

Product Description

Agfa Graphic Art Imagesetter Film For Offset Printing
Model: ECOO-TDS

Brief introduction:

Recording films has been the standard in the printing business for years, and your company can continue to use them. We offer original Agfa films produced in Belgium, which are then recut and repackaged at the Shanghai Agfa branch.

Our films feature an open system, high-speed, red-sensitive technology with hard dot image quality. They are designed for exposure in image setters equipped with HeNe lasers (630nm-670nm) or red laser diodes, ensuring perfect processing with compatible chemistries.

Specification:

Model	ECOO-TDS
Plate Type	Alliance far red film
Spectral Sensitivity	HeNe laser and red laser diode (630-670nm)
Description	Emulsion coated on a 0.10 mm antistatic polyester base
Practical Photographic Properties with Different Engine
Engine	Accuset	Avantra
Int. Setting	170	230
Practical Density	D.4.00-4.20	D.4.10-4.30
5%	5%	5%
50%	57%	53%
95%	98%	96%
Developer	Agfa developers
Processing time	20-40 sec
Processing temperature	35ºC or 95ºF
Developer Replenishment (eg, ACD/ASD)	15% exposure	50ml/m²
	50% exposure	150ml/m²
	85% exposure	250ml/m²
Anti-OX replenishment	1000 ml/24h=0.264 US gallons/24h
Fixer	Agfa fixer
Fixing temperature	32ºC or 90ºF
Fixer replenishment (Without Fixer electrolysis)	15% exposure	500 ml/m²
	50% exposure	300ml/m²
	85% exposure	100ml/m²
Fixer replenishment with Fixer electrolysis	125 ml/m²
Practical set-up density	D 4.00-D.4.20 (dot gain depending on the optical quality of the imagesetter)

Chemical Compatibility	Processable in all rapid access chemistries and in main hard dot chemistries such as RA2000, Fuji HQ QRD-1, AND QRD-1P
Dimensional Stability	Humidity coef: 0.10mm base, Crh 0.016mm/m/%RH Temp. coef: 0.10mm base, Cot 0.018mm/m/1ºC

Safe light	Dark Green recommended: Encapsulite T20/ND.75 or equivalent
Storage	The films are preferably stored in a cool dry place temperature below 20ºC and relative humidity between 30% and 60%

Features:
Excellent image quality: very good sharpness and high practical density
Very wide System latitude: Wide processing & exposure latitude
Very good Day to day consistency Very good batch-to-batch consistency
Convenience and ease of use because of available ECO equipment
Ecological & Economical replenishment, very Low chemistry consumption.
Linear output for conventional screening Approved for stochastic screening
Anti-static before and after processing
Open system: perfect processing in compatible chemistries

Sizes:
390mmX60m 610mmX60m
406mmX60m 660mmX60m
457mmX60m 813mmX60m
508mmX60m 838mmX60m
558mmX60m 914mmX60m
Other sizes are also available as required.

Unpacking:

**Daylight Loading:** The film for daylight loading can be loaded into the special cassette of the laser image output machine under normal daylight conditions.

**Darkroom Loading:** The film for darkroom loading should be loaded into the special cassette of the laser image output machine under a special dark green light or in complete darkness.

**Handling Precautions:** Handle the film with care to prevent damage from friction, folding, oil, and fingerprints.

Storage:

Store the films in a cool, dry place with a temperature not exceeding 20°C and a relative humidity (RH) below 65%. Excessive warmth and humidity can shorten the film's shelf life. Keep the films away from radiation, corrosive substances, and direct sunlight.
