| ECOO UV-400Q Series Automatic CTP Specifications | ||||
| Model | UV-400QF | UV-400QS | UV-400QE | |
| Exposing Method | External Drum | |||
| Imaging System | 48-channel | 32-channel | 24-channel | |
| Discrete 400-410nm laser diode | ||||
|
Throughput |
30PPH | 25PPH | 18PPH | |
| 800 x 660mm, 2400dpi | ||||
| Plate Sizes | Max.800mm x 660mm Min.235mm x 335mm |
|||
| Media Type | UV-CTP plate ,high-sensitive PS plate | |||
| Plate Thickness | 0.15mm to 0.30mm | |||
| Resolution | Standard: 2400 dpi or 1200 dpi (Optional) | |||
| Repeatability | 0.01mm | |||
| Interface | Optical Fiber(Fiber-way) | |||
| Plate Loading | Automatic or Manual | |||
| Net Weight | 1100kg | |||
| Machine Size (WxLxH)mm |
1450x1350x1290 | |||
| Power Supply | single phase:220AC,+ 6%,- 10%, power Consumption:4KW | |||
| Environment | recommended:21-25℃, Max.18-26℃, humidity:40-70% | |||
