Home /Products/CTP Plate Machine/FL4835 Flexo CTP Plate Machine with 48"×35" Max Breadth 3/5 m2/h Output Speed and 3 Years Warranty

FL4835 Flexo CTP Plate Machine with 48"×35" Max Breadth 3/5 m2/h Output Speed and 3 Years Warranty

1SET
MOQ
Negotiable
Price
FL4835 Flexo CTP Plate Machine with 48"×35" Max Breadth 3/5 m2/h Output Speed and 3 Years Warranty
Features Gallery Product Description Request A Quote
Features
Specifications
Output Speed: 3/5 M2/h
Max.Breadth: 48"×35"/1200mm×1020mm
Laser Channels: 256CH
Plate Thickness: 0.14-6.35(mm)
Resolution: 4000dpi , Optional:2540dpi
Plate Type: Dry Ablation Film, Digital Water Washing Letterpress Plate. Digital Water Washing Flexo Plate, Digital Solvent Washing Flexo Plate
Machine Condition: New
Warranty: 3years Or Lifetime
Highlight:

2.84mm Thickness CTP Plate Machine

,

Flexo Photopolymer CTP Plate Machine

,

Digital CTP Plate Machine
Basic Infomation
Place of Origin: China
Brand Name: EcooGraphix
Certification: CE,SGS
Model Number: FL4835
Payment & Shipping Terms
Packaging Details: Standard export packing
Delivery Time: 30 DAYS
Payment Terms: T/T
Supply Ability: 500SETS
Product Description
FL4835 Flexo Printing Photopolymer Cliche Digital CTP Plate Machine
Equipment Advantages
  • High energy power fiber laser device at 5080dpi can output a full 50" x B0" plate in just 30 minutes, with 10% productivity boost for urgent jobs
  • Unique 256-channel independent modulating technology with rectangular laser spot for superior dot quality and image performance
  • H256 laser head with high power magnification optical system achieves 5080dpi optical resolution
  • Precision imaging: 15μm for slant/circular lines, 5μm for vertical/horizontal lines, improving color fidelity by 30%
  • Flexible output modes: 2540dpi option with double line overlapping exposure for 150% productivity increase
  • Voice coil motor enables dynamic auto-focus for consistent exposure on non-uniform flexo plate surfaces
  • Double/triple line overlapping functions for superior LAMS ablation quality and efficiency
  • Instant temperature monitoring and laser head pre-calibration ensure exposure stability and reliability
Specifications
Model EcooSetter Flexo CTP FL-4835E
Laser Channel 256-channel
Output Speed 3~5 sqm/h
Max. Breadth 48"×35"/1200mm×1020mm
Plate Thickness 0.14mm - 6.35mm
Laser Power High power semiconductor laser diode
Plate Type Digital relief flexo plate (water-wash), Digital flexo plate (water/solvent-wash), Steel based digital plates
Application Label and trademark
Resolutions 4000dpi
Plate Loading Manual load and unload
Interface USB2.0
Focus Adjust Dynamic auto-focus
Device Size 2,970×1,705×1,537mm
Net Weight 2500Kg
Power 220V/50Hz, 60Hz, mainframe 1.5KW + Vacuum 4.5KW
Environment Recommended temperature: 18-30ºC, Humidity: 10-80%
Major Highlights
  • Superior dot quality: 1%-99% dot reproduction, up to 250lpi screening, 4000 dpi or 2540dpi optional
  • Fully qualified: Compatible with all thermal non-process and process plates
  • Robust and simple: User-friendly design minimizes human error
  • Premium components: World-class parts from Japan, USA, and Germany
  • Long lifetime: Laser diodes last over 10,000 imaging hours (~20,000 plates)
  • 3-year warranty: Free replacement of all parts, with low-cost replacements afterward
  • Comprehensive service: Factory installation/training, regular maintenance, 7x24 support
  • Proven worldwide: Over 6,000 units installed globally in past decade
Similar Models Comparison
Model EcooSetter FL-600E EcooSetter FL-600S EcooSetter FL-800E EcooSetter FL-800S EcooSetter FL-4835E EcooSetter FL-5080E
Laser Channel 16CH 32CH 16CH 32CH 256CH 256CH
Output Speed 1.25 m²/h 2.5 m²/h 1.25 m²/h 2.5 m²/h 3 m²/h 3 m²/h
Max. Breadth 26" x 17" 25"x30" 48"×35" 48"×35" 48"×35" 50"×80"
Plate Thickness 0.14mm - 1.14mm 0.14mm-1.7mm 0.14mm-6.35mm 0.14mm-6.35mm 0.14mm-6.35mm 0.14mm-6.35mm
FL4835 Flexo CTP Plate Machine with 48"×35" Max Breadth 3/5 m2/h Output Speed and 3 Years Warranty 0 FL4835 Flexo CTP Plate Machine with 48"×35" Max Breadth 3/5 m2/h Output Speed and 3 Years Warranty 1 FL4835 Flexo CTP Plate Machine with 48"×35" Max Breadth 3/5 m2/h Output Speed and 3 Years Warranty 2 FL4835 Flexo CTP Plate Machine with 48"×35" Max Breadth 3/5 m2/h Output Speed and 3 Years Warranty 3 FL4835 Flexo CTP Plate Machine with 48"×35" Max Breadth 3/5 m2/h Output Speed and 3 Years Warranty 4 FL4835 Flexo CTP Plate Machine with 48"×35" Max Breadth 3/5 m2/h Output Speed and 3 Years Warranty 5 FL4835 Flexo CTP Plate Machine with 48"×35" Max Breadth 3/5 m2/h Output Speed and 3 Years Warranty 6
Frequently Asked Questions
What are your main products?

We specialize in prepress equipment including 4up/8up Online/Offline Thermal CTP, CTCP, VLF CTP and CTCP, Flexo CTP, Processors, Offset Plates, inks, blankets, and postpress packing equipment. Our products are well-received in USA, Canada, Mexico, Colombia, Turkey, Hungary, South Africa and other markets.

Where is your factory located?

Our CTP machine factory is in Hangzhou city, approximately 1.5 hours by train from Shanghai. We welcome visits to our facility.

What is your warranty policy?

3-year warranty for Laser Head and main spare parts (1 year for Processor). Lifetime warranty for CTP machine when combined with our plates.

What is the typical lead time?

Usually 10-30 days, though we strive to accommodate urgent requests.

Do you supply Workflow and RIP software?

Yes, we provide Workflow Brain New and RIP Compose V13.

What about installation and after-sales support?

Our engineers provide installation and training (buyer covers travel expenses). We offer 24/7 technical support for any issues.
