Ecoographix Inkjet Textile Digital Printer of 130 Sqm/Hr
Product Description
Application:
1. Up to 240 sqm/hr Printing Speed
2. Creative dual-row print head Allignment
3. Tension-adjustable continuous winding/unwinding control technology
4. Anti-scratch print head protection design
5. Industrial ink supply system
6. High precision belt conveying system
7. Specialized conveyor belt for digital printing
8. Automated textile rolling design
9. Intelligent and user-friendly operation interface
10. Magnetic linear motor and steel rail beam.
Specification
| Digital Inkjet Textile Printing Machine | |
| Model | HM1800B |
| Print Head | Water-based Kyocera print head |
| Print Head Qty | 4-8 pcs |
| Max Printing Resolution | 600x1800dpi |
| Production Speed | 600x600dpi(2pass): 260sqm/hr; 600x900dpi(3pass): 190sqm/hr; 600x1200dpi(4pass): 130sqm/hr |
| Printing Height | 2-30mm |
| Media Conveying | Continuous belt-conveying, Auto constant tension feeding&taking up, Fabric spreading, Tension-free entry unit (optional) |
| Max Printing Width | 1900mm |
| Max Media Width | 1920mm |
| Dimension (L/W/H) | Printer: 4656mm x 2304mm x 2277mm; Dryer: 2190mm x 2850mm x 1780mm; |
| Package: 4850mm x 2250mm x 2250mm; Package: 2280mm x 2960mm x 1730mm | |
| Ink Type | Reactive, acid, sublimation (direct or transfer), pigment |
| Ink Color | Cyan, Magenta, Yellow, Black+four spot colors (optional) |
| Ink Supply | Peristaltic-pump ink supply, Ink degassing, Auto negative pressure system |
| Belt Cleaning | Auto brush and sponge roller washing system |
| Media Type | Cotton, linen, silk, nylon, polyester, blended, elastic fabrics, etc |
| Max Roll Diameter | 400mm (standard unwinder&winder roll) |
| Max Roll Weight | 100kg (Full width, standard unwinder&winder roll) |
| Drying | Belt+Hot air+IR |
| Rip Software | Neostampa or Texprint |
| Power supply | Printer: AC380V three phase | 30A(6.5kW)+27A(6kW) | 50Hz/60Hz; Dryer: AC380V three phase | 22A(15.9kW) | 50Hz/60Hz |
| Compressed water supply | 0.6 Mpa | 0.9mm³/hr |
| Compressed air supply | 0.6 Mpa | 0.15m³/hr(dry, no oil or water) |
| Working Environment | Temperature: 20~28ºC(68~77ºF); Relative humidity: 45-60%(no condensing) |
More Details
Producing And Packaging
FAQ
1. Production Lead Time: about 30days after received the deposit
2. Payment Term: 30% deposit, 70% before shipping
3. Warranty: One year warranty(For machine parts, we have one year guarantee. For motor, three months guarantee. For spare parts touching with ink, such as ink sat, ink pump, printhead, we have no guarantee. It's all the same in the market.)
4. Installation and Training:We help the installation through online Video , if you have problem when you use the machine, we will train you online. These are all for free. If needed, we can also send engineers to your place, but you need to pay their travel expense.
