50m/Mim Inkjet Digital Printing Machine For Label Printing

1 SET
MOQ
Negotiable
Price
50m/Mim Inkjet Digital Printing Machine For Label Printing
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: Inkjet Digital Printing Machine
Usage: Label Printer
Printing Speed: 50m/MIM
Color & Page: Multi-Colour Printing Press
Highest Resolution: 600*1200dpi
Max Print Width: 324mm
Ink Type: UV Ink
Substrate Type: Pet/PVC/PP/PE/BOPP/ And Other Mono Film Materials
Substrate Width: Max 350mm
Feeding: Roll To Roll
Roll Diameter: Max. 650mm
Specification: 4510mm× 2410mm× 2680mm
High Light:

600*1200dpi Digital Inkjet Printer

,

50m/Mim Inkjet Digital Printing Machine

,

Label Flatbed Inkjet Printer
Basic Infomation
Place of Origin: China
Brand Name: EcooGraphix
Certification: ISO9000, CE
Model Number: Ecoo-HTC330
Payment & Shipping Terms
Payment Terms: L/C, T/T
Supply Ability: 500 Sets Per Year
Product Description

Ecoographix Inkjet Digital Printing Machine For Label Printing

50m/Mim Inkjet Digital Printing Machine For Label Printing 0



Product Description

Introduction:

The HTC330 uses top existing high-speed and high-precision industrial on-demand piezoelectric printing head with the accuracy of 600×600 dpi is adopted to achieve high-quality images. The printing speed comes up to 50m/min and the printing head has durable service life.

The inkjet printing is a non-contact printing method, featuring for being all digital and high tolerance of printing substrate, like paper, PVC, PET, PE, BOPP, gold and siler foil and other materials.
It is capable to handle full color printing on transparent or non-transparent material without plate making.
The computer to label digital procedures makes it easy to print variable data involving one dimensional code, QR code, serial number, and dot matrix code and
achieves one standard and one label corresponding to appropriate code,meeting the requirements of anti counterfeiting traceability orders.
Easy to use typesetting output software to quick switch of printing jobs without pending operation,improving the work efficiency.

Machine Features:

1. The diversified, high-rate and low-rate of products are available and cycling duration is short.
2. HTC features with large capacity and fast rate of order alteration without the necessity of equipment
adjustment, and the production capacity is double or above compared to traditional equipment.
3. Exclusive RIP software and original ink factory waveform are supported. End users can create own ICC to make high quality printing performance, combined with unique texture of UV ink.
For example, the automatic trapping function has stored ICC curve of common materials in the market, so that it is convenient to select the best featured file.
4. Suitable for a variety of media materials. The printing heads are fully automated to prevent clogging. The test document integration and one-button test printing head print results are supported.





Specification



Model ECOO HTC 330
Highest Resolution 600*1200dpi / 600*1200dpi
Max print width 324mm
Printing speed 50m/mim
Ink type UV ink
Color CMYK+White
Substrate type PET/PVC/PP/PE/BOPP/ and other mono film materials, synthetic paper, coated paper, aluminum foil and other special materials.
Substrate width Max 350mm
Substrate thickness 0.01-0.8mm
Feeding Roll to roll
Roll diameter Max. 650mm
UV curing Composed of 5 sets of LED and a set of 5kw UV lamps and equipped with water-cooled roller to ensure that the material does not deform during final curing and may dry heat-deformable materials including PVC.PET aluminum foil.
Input format PDF,JPEG,BMP and other common file formats
Dimension 4510mm×2410mm×2680mm
Weight 3200kg
Power Three-phase 380VAC50/60HZ10KW
Air requirements Industrial air source 0.6-0.8Mba, compressed
Operating environment Temperature: 16ºC-32ºC, Humidity: 40%-60% relative humidity



Rich applications:

General Labels: beverages, food and medicine, chemical solvent, electronic appliance, transport tickets
Packaging: daily supplies, monofilms (PE/PP/PET/PVC), wrap around labels
Others: jewelry tag, garment tag, variable anti-counterfeiting, folding cartons

50m/Mim Inkjet Digital Printing Machine For Label Printing 1

Applicable for label orders with limited quantities, multiple varieties and tight requirement on timeliness.

50m/Mim Inkjet Digital Printing Machine For Label Printing 2

Applicable for the printing of serial number, one dimensional code,QR code, and others coming with variable information and anti-counterfeiting traceable label.

50m/Mim Inkjet Digital Printing Machine For Label Printing 3

Applicable for types of personalized qualitative and new products market services developed and invested.




More details



50m/Mim Inkjet Digital Printing Machine For Label Printing 4



50m/Mim Inkjet Digital Printing Machine For Label Printing 5



FAQ

1. What are your main products?
We Ecoographix is a specialized supplier of printing machines and consumables. We cover both digital printing and offset printing, including prepress, pressroom and post press, focusing on packaging printing and book printing. We have hundreds of users all over the world. We bring forward top quality of Chinese printing products to meet diversified printing requirements.

2.Where is your factory?
Our sale office is in Hangzhou, one hour by train away from Shanghai. Our factories are in Shanghai, Wenzhou, Suzhou and Nanyang.

3. What is your warranty?
Normally 1 year.

4. Can you also supply the software?
Yes

5. What about the Installation and after-sales technician support?
Our engineer can go to help the installation and provide the necessary training. The buyer should take the round air plane tickets and service charge and the local accommodation cost. Any problems or questions,we will be at your disposal 7x24 hours.
