5Colors Digital Roll Label Sticker UV Inkjet Printing Machine HTS330
HTS330 is the digital label printing machine, industrial on-demand piezoelectric nozzle with the accuracy of 600×600 dpi is adopted, achieving high-quality images. The printing speed comes up to 50m/min and the nozzle feature with durable service life.
Applications: Wine Labels, Cosmetic Labels, Luxury labels ,Medical labels,Washi tapes,pouch packages and so on.
| Printing technology | Single PASSUV inkjet technology, DOD industrial sprinkler, Class 4 grayscale |
| Resolution | DPI 600X600dpi or 600x1200dpi The DPI/ speed is 1,200 dpi 25m/min.2400 dpi 12.5m/min. |
| Printing speed / min (max.) | 50 m/min |
| Material type | Coated or non-coated paper, transparent or opaque media |
| Rewinder and unwinder material roll diameter |
Maximum diameter of 650mm 650mm |
| Feed let width | 250mm,350mm |
| Print width | 216mm(10pcs print heads),324mm(15pcs print heads) |
| Ink. | LED curing UV ink |
| Print color group | CMYK with White ink and oil. |
| Mechanical size (L W H) | 4510 mmx2410 mm x2580 mm |
| Mechanical weight | About 3.2 tons |
| Enter the gas source | 0.6-0.8 Mp |
| Enter the power supply | Three-phase, 380VAC 50/60HZ 10KW. |
| Accept the file format | Common file formats such as PDF.JPEG.BMP.... |
| Computer hardware. | Motherboard HTS-PRIME Z370-A, graphics card HTS-GTX1070-08Go |
| Cobearing thickness | 0.01~0.8mm roll material |
| Image processor | RIP bundle, which saves RIP time for big data files with synchronous printing and RIP,. |
| LED/UV | It consists of 4 sets of LED and a set of 10KW UV lamps with water-cooled irradiation to ensure that the material does not deform during the final curing and can dry heat-easily deformed materials such as PVC.PET aluminum foil |
| Temperature range. | 18-30°C |
| Ink storage temperature. | 16-32°C |
| Humidity range. | 40-60% |
