5 Colors Inkjet Digital Label Printing Machine Drop On Demand

1 set
5 Colors Inkjet Digital Label Printing Machine Drop On Demand
Features Gallery Product Description Request A Quote
Model: HTC330
Type: Digital Inkjet Label Printer
Printing Width: 314mm
Printing Speed: 50 M/min
Printing Head: Kyocera
Colors: CMYK+W
Application: PET/PVC/PP/PE/BOPP/ And Other Mono Film Materials,
Optional Functions: Uv Varnishing, Cold Foil Stamping
High Light:

50m/min Digital Label Printing Machine


Inkjet Digital Label Printing Machine


Uv Varnishing Label Printers

Basic Infomation
Place of Origin: China
Brand Name: ecoographix
Certification: ISO, CE
Model Number: HTC 330
Payment & Shipping Terms
Packaging Details: wooden case
Delivery Time: 35-60 days
Payment Terms: L/C, T/T
Supply Ability: 100 set per year
Product Description


5 Colors Inkjet Digital Label Printing Machine Drop On Demand 0


With the growing pursuit of product diversification, more and more products need to be labeled and packaged with comprehensive designs and tailor-made marks. Label printing company and some enterprises need label printers with simple printing procedures and low switch printing costs to handle more and more short label printing jobs. Thus, digital printing is being more and more important.

The HTC330 is a high speed ink-jet label printing machine. It is able to handle most color requirements and printing substrate. For being industrial fast, it is very popular.


Technical parameter

ECOO HTC 330 Digital Label Printer Machine

Model Ecoo HTC 330
Highest Resolution 600*1200dpi / 600*1200dpi
Max print width 324mm
Printing speed 50m/mim
Ink type UV ink
Color CMYK+White
Substrate type PET/PVC/PP/PE/BOPP/ and other mono film materials, synthetic paper, coated paper, aluminum foil and other special materials.
Substrate width Max 350mm
Substrate thickness 0.01-0.8mm
Feeding Roll to roll
Roll diameter Max. 650mm
UV curing

Composed of 5 sets of LED and a set of 5kw UV lamps and equipped with water-cooled roller to ensure that the material does

not deform during final curing and may dry heat-deformable materials including PVC.PET aluminum foil.

Input format PDF,JPEG,BMP and other common file formats
Dimension 4510mm×2410mm×2680mm
Weight 3200kg
Power Three-phase 380VAC50/60HZ10KW
Air requirements Industrial air source 0.6-0.8Mba, compressed
Operating environment Temperature: 16℃-32℃, Humidity: 40%-60% relative humidity



Features and advantages


1. ink


5 Colors Inkjet Digital Label Printing Machine Drop On Demand 1


UV/LED ink has good softness, high scratch resistance, excellent outdoor sunscreen and waterproof performance, and excellent optical density. Dark blue has a light fastness of 8 grades and redand yellow has a light fastness of 6 grades.

The color is highly reductive and highly concentrated.

Ultra wide color reproductivity.

This is an advanced material dispersion technology that has beendeveloped for many years, which is very important for ink-jet ink. It can improve the spray performance and printing consistency,and improve the ink performance by accurately dispersing fine-grained pigment and keeping each particle separate.

Excellent hiding power and whiteness.The white hiding power ontransparent and silver materials can reach the effect

2. printing  heads

5 Colors Inkjet Digital Label Printing Machine Drop On Demand 2

Print head brand Kyocera Effective printing width 108.25mm
Working life 5 years Quantity 15 pcs
Applied ink type UV ink type Max. Driving Frequency 20 khz
Printing head size 200*25*59.3mm Max. Printing speed 600 dpi 846.7mm/s, equals to 50.8m/min
Dry weight 420 g Ink amount 3/6/13PL
Total nozzle quantity 12556 Ink viscosity 5.5-6.5 MPA*S
Standard resolution 600*600 dpi Input voltage 3V is logic, 29V is drive


1:Equipped with temperature controlled accumulator and thermistor

2: Large Print Width of single printing head

3: Reduce the overall printing nozzle consumption

4: Reduce the difficulty and time of printing head connection

5: Printing width: 108mm-112mm
