Semi-automatic Single Paper Square Bottom Bag Making Machine
EcooGraphix is a professional supplier of eco-friendly paper processing machines and paper products. Following the enterprise development mission of “Create Value for Customers.
| Bag Making Machine | |||
| Model | Ecoo-22KL | Ecoo-35KL | Ecoo-45KL |
| Bag Width(mm) | 120 ~ 250 | 180 ~ 350 | 220 ~ 450 |
| Bottom Width(mm) | 50 ~ 110 | 70 ~ 160 | 70 ~ 170 |
| Tube Length(mm) | 210 ~ 410 | 280 ~ 540 | 320 ~ 560 |
| Sheet Width(mm) | 325 ~ 720 | 530 ~ 1050 | 610 ~ 1260 |
| Sheet Length(mm) | 250 ~ 410 | 340 ~ 600 | 380 ~ 620 |
| Sheet Thickness | 120~300g/m2 (TP) | ||
| Head-card Width (mm) | 20 ~ 50 | ||
| Head-card Length (mm) | 90 ~ 170 | 150 ~ 270 | 190 ~ 370 |
| Head-card Thickness | 200~ 450 g/m2 | ||
| Flip Width (mm) | 25~40 | ||
| Punching Diameter | 4mm, 5mm, 6mm | ||
| Punching Distance | 60,80,100mm | 80,100,120mm | 100,120,140mm |
| Power Consumption (kw) | 28 | ||
| Machine Size(mm) | 1300W | 1700W | 1910W |
| 15400L | 16510L | 16510L | |
| 2010H | 2460H | 2460H | |
| Max. Speed (Bags/min) | 70 | ||
| This machine puts a handle rope between two pieces of paper and fixes it together with hot melt glue as a hand grip. The handle material can be twisted paper rope,twisted p.p.rope,acrylic resin rope,etc. The handle making machine is installed parallel | Pasting handles that made by handle making machine or cardboard to the mouth of the main sheet paper and folding.This is pasting unit for handles or cardboard (double pasting style) | This unit punches two holes as well as four holes,normally there are 3 kinds of holes diameters, 4,6 and 8mm. And holes distance included two kinds, 80 to 200mm. It's possible to set up a banana type holes die cutting system as option. |
| Organ line adjustment and pressure adjustment are controlled by a digital display, greatly reducing the time for adjusting and improved production efficiency. | It can automatically calculate the quantity and more convenient to collect bags | Only needs to adjust one side of the cylinder, the other two sides will be adjusted automatically. Greatly reduced adjustment time and improved production efficiency. |
FAQ:
Q:Why choose us ?
A: We are manufacturer .We have strict QC policy to control the producing process,strong technica team and after-sales service team to offer best support,try our best to exceeding your expectations.
-Inquiry will be replied with 24 hours.
-OEM service is available.
-Protect your design & information.
Q:Do you have the CNC workshops ?
-We have our own CNCworkshops,we produces the molds by ourselves.
Q: Can I have sample before order?
A: Yes ,free samples can be sent out,the freight cost is paid by you.
(1).You can provide your a/c like DHL/Fedex/TNT ect.
(2).You can call your courier to pick up at our office.
(3).You can pay us the freight cost by T/T.
Q: Can you make the customized paper cone ?
A: Yes , please show us your sample first .
Q: What time for delivery ?
A: Machine about 45 days after get your deposit.
Q: Engineer oversea service ?
A: Yes ,we can send engineer to help you install ,training worker until the machine normal running.
-If you meet any problem at any time,we could offer the technical support on line as well.
Q: What payment term ?
A: T/T 30% down payment ,balance before delivery ,or LC at sight or D/P etc.
Q: Do you have any certificates?
A:We have CE and ISO certificates .
