CMYK Sticker PE PET Inkjet Label Printing Machine 7.2m/Min 1200x2400dpi

1SET
MOQ
Negotiable
Price
CMYK Sticker PE PET Inkjet Label Printing Machine 7.2m/Min 1200x2400dpi
Features Gallery Product Description Request A Quote
Features
Specifications
Resolution: 1200*2400 Dpi
Variable Image System: PDF,Optional Barcode System
Printing Speed: 7.2m/min
Substrates: Offset, Digital, Plastics
Warranty: One Year
Weight: 423KGS
Highlight:

CMYK Inkjet Label Printing Machine

,

Label Printing Machine 7.2m/Min

,

1200x2400dpi Label Printing Machine

Basic Infomation
Place of Origin: CHINA
Brand Name: ECOOGRAPHIX
Certification: CE
Model Number: Ecoo-VP320
Payment & Shipping Terms
Packaging Details: standard export packing
Delivery Time: about 20days
Payment Terms: L/C, T/T
Supply Ability: 300SET
Product Description

4Colors CMYK Digital Label Inkjet Printer for Sticker PE PET





Introduction:

With the development of society and people's pursuit of product diversification, more and more products need to be labeled and customized. Label printing company and some enterprises need digital label printers to save printing costs and time costs. Lack of labor force, the operators who are professional for traditional printing machine are becoming less and less, The advantage of digital products are that easy to operate and maintain gradually enter the label printing market, it will replace the traditional printing press step by step. Ecoo Digital Label Printer meets the different needs of various customers with suitable printing costs and lower product prices.



1.Published performance results based on laboratory testing. Individual results may vary.
2.This product is designed and engineered to operate only with genuine iSys Label consumables and certified media substrates. Please contact iSys for the most current
Certified Media List of substrates available
3.Letter-size sheets at 5% coverage. Printer ships with a 7,500 page set of starter toners,

4. Based on 500 cut-sheet pages/job. iSys Label reserves the right to change product specifications without notice. Trademarks are the property of their respective manufacturers.



Software Features:

In order to get a high quality printing, Ecoo researched and developed typical and easy a printer software for VP320C. This software has friendly interface, and easy to understand. Automatically edit jobs together, integrated with programmatic printing. PhaserMatch 5 color management system was nested to printing software. You can get best image label and finish the jobs easily.





Model Ecoo-VP320
Print speed Up to 7.26 meters/min (30ft/min)
Print technology 4 Color (CMYK) LED technology
Preparing time 533MHz
Printer processor less than 28s
Data port (Standard)10BASE-T/100BASE-TX, USB2.0;(Options) internet 1000BASE-T, IEEE1284-B
Media width 304mm
Print width Min 210mm Max 308mm
Print length Max 1200mm Min 98mm
Substrate types Paper: Paper, High glossy paper,Matt paper; Film: PET, PP, PE, GHS..
All of media was tested in special environment, not tested media possible can't be used
Print quality 1200x2400dpi
Toner supplies

CMY-18500sheets (A4, 5% coverage rate) K-26000 sheets (A4, 5%

coverage rate);( Rated according to ISO/IEC 19798 guidelines)

Drum supplies CMYK-100000 (print runs according to the operating cycle, Medium size and the direction to change)
Size 1400*810*1600mm
Weight Print engine:423KGS
Operating environment Temperature:20℃-23℃,Humidity: 45-55% RH
Power supply 110-127 VAC,50-60Hz@2800W,220-240 VAC ,50-60Hz@2800W
Power consumption (AC220-240V) sleep 75W;waiting 100W;running 1100W
Monthly running job Max.20000sqm (advice)
Warranty 1 year (excluding high consumable parts)



CMYK Sticker PE PET Inkjet Label Printing Machine 7.2m/Min 1200x2400dpi 0

CMYK Sticker PE PET Inkjet Label Printing Machine 7.2m/Min 1200x2400dpi 1CMYK Sticker PE PET Inkjet Label Printing Machine 7.2m/Min 1200x2400dpi 2

CMYK Sticker PE PET Inkjet Label Printing Machine 7.2m/Min 1200x2400dpi 3





Auto web guide tension system:

1 For tension adjustment of all media

2 Auto calculate the length of feeding

3 Ultrasonic detect edge of media to avoid media loading twisty

4 Avoid printing image to stretched and twisted

5 Increase the lifespam of engine



Consumables:

Toner K: print 26 sheets A4 with 5% coverage

Toner CMY: print 18.5K sheets A4 with 5% coverage

Drum: 100K sheets A4

Waste box: 300k sheets A4

Transfer cleaner: 200k sheets A4

Transfer roller: 200k sheets A4

Developer CMYK: 480k sheets A4

Developer house: 480k sheets A4

Fuser: 480k sheets A4

Transfer belt Assy: 480k sheets A4

CMYK Sticker PE PET Inkjet Label Printing Machine 7.2m/Min 1200x2400dpi 4

CMYK Sticker PE PET Inkjet Label Printing Machine 7.2m/Min 1200x2400dpi 5
